Quick Details
-
Brand Name:
-
MOKO
-
Supplier Type:
-
Factory
-
Copper Thickness:
-
1OZ
-
Product name:
-
PCBA
-
Certificate:
-
ISO9001:2008 / U L / CE / ROHS
-
Base Material:
-
FR-4,CEM-1,CEM-3, Rogers, Arlon, Polymide
-
Solder mask:
-
White Black Green Blue Red
-
Application:
-
Electronic Products
-
Testing Service:
-
AOI X-Ray Function Test
-
Layer:
-
1-22 Layers
-
Standard:
-
IPC-A-610G
-
Shipping:
-
DHL UPS FedEx
Quick Details
-
Model Number:
-
MK001BA01
-
Type:
-
PCBA, Customizable
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MOKO
-
Supplier Type:
-
Factory
-
Copper Thickness:
-
1OZ
-
Product name:
-
PCBA
-
Certificate:
-
ISO9001:2008 / U L / CE / ROHS
-
Base Material:
-
FR-4,CEM-1,CEM-3, Rogers, Arlon, Polymide
-
Solder mask:
-
White Black Green Blue Red
-
Application:
-
Electronic Products
-
Testing Service:
-
AOI X-Ray Function Test
-
Layer:
-
1-22 Layers
-
Standard:
-
IPC-A-610G
-
Shipping:
-
DHL UPS FedEx
Our Service
1.PCB fabrication and PCB assembly;
2.PCBA programming & functional testing;
3.Electronic components purchasing service;
4.Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
Product Description
Specification
|
PCB Technical Specification
|
|
|
|
Order Quantity
|
1-500,000
|
|
|
Layer
|
1,2,4,6,up to 22 layers
|
|
|
Material
|
FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
|
|
|
PCB type
|
Rigid, flexible, rigid-flexible
|
|
|
Shape
|
Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
|
|
|
Max PCB dimensions
|
20inch*20inch or 500mm*500mm
|
|
|
Thickness
|
0.4~4.0mm
|
|
|
Thickness tolerance
|
± 10%
|
|
|
Copper thickness
|
1/2OZ 1OZ 2OZ 3OZ
|
|
|
Copper thickness tolerance
|
± 0.25oz
|
|
|
Surface finish
|
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
|
|
|
Solder mask
|
Green, red, white, yellow, blue, black, etc
|
|
|
Silk screen
|
White, yellow, black, or negative, etc
|
|
|
Silk screen min line width
|
0.006'' or 0.15mm
|
|
|
Min drill hole diameter
|
0.01'',0.25mm.or 10 mil
|
|
|
Min trace/gap
|
0.075mm or 3mil
|
|
|
PCB cutting
|
Shear,V-score,tab-routed
|
|
|
|
|
|
|
|
PCB Assembly Capabilities
|
|
|
|
|
|||||
|
Item
|
Technical Parameter
|
|
|
|
|
|||||
|
SMT Jointing Min. Space
|
0201mm
|
|
|
|
|
|||||
|
QFP Space
|
Pitch 0.3mm
|
|
|
|
|
|||||
|
Min. Package
|
0201
|
|
|
|
|
|||||
|
Min. Size
|
2*2 inch(50*50mm)
|
|
|
|
|
|||||
|
Max. Size
|
14*22 inch(350*550mm)
|
|
|
|
|
|||||
|
Placement Precision
|
±0.01mm
|
|
|
|
|
|||||
|
Placement Precision
|
QFP, SOP, PLCC, BGA
|
|
|
|
|
|||||
|
Placement Capability
|
0805, 0603, 0402, 0201
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
PCB Lead time (workday(s))
|
|
|
|
|
|
|||||
|
|
Single, Double-sided
|
4 layer
|
6 layer
|
Over 8 layer
|
HDI
|
|||||
|
Sample Lead time (Normal)
|
5-6
|
6-7
|
7-8
|
10-12
|
10-12
|
|||||
|
Sample Lead time (Faster)
|
48-72 hours
|
5
|
6
|
6-7
|
12
|
|||||
|
Mass production lead time
|
7-9
|
10-12
|
13-15
|
16
|
20
|
|||||
|
PCB Assembly Lead time
|
|
|
|
|
|
|||||
|
Sample Lead time
|
PCB Fab+Components Sourcing+PCBA=15 workdays
|
|
|
|
|
|||||
|
Mass production lead time
|
PCB Fab+Components Sourcing+PCBA=20 workdays
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|||||
PCB Assembly Process
Testing
Why Choose Us
1. Fast
response
;
2.
Lower cost;
3. Two-year guarantee.
With more than 10-year EMS service experience, we have established good businedd relationship with components manufacturers, and distributors. As we are sourcing these components together, which will benefit to get a good price from manufacturers.
The raw material in low price makes your own products more competitive in your market, in the meantime you can get 2 years guarantee with no worries from us; That is why we can keep good quality and competitive prices for global valued customers.
