Quick Details
-
Engine Type:
-
4 Stroke
-
Engine:
-
Water Cooled
-
Transmission:
-
shaft drive
-
Brake:
-
Front/Rear Hydraulic Disc Brake
-
ATV:
-
Chinese Atv
-
MAX SPEED:
-
90km/h
-
Type:
-
4-stroke 12HP
-
Piston displacement:
-
250CC
-
Starting system:
-
CDI Electric Start
-
Battery:
-
12V 9Ah
Quick Details
-
Displacement:
-
250cc
-
Brand Name:
-
SIHAO
-
Place of Origin:
-
Zhejiang, China
-
Engine Type:
-
4 Stroke
-
Engine:
-
Water Cooled
-
Transmission:
-
shaft drive
-
Brake:
-
Front/Rear Hydraulic Disc Brake
-
ATV:
-
Chinese Atv
-
MAX SPEED:
-
90km/h
-
Type:
-
4-stroke 12HP
-
Piston displacement:
-
250CC
-
Starting system:
-
CDI Electric Start
-
Battery:
-
12V 9Ah
|
1.Engine Type |
|
|
Displacement |
250cc single cylinder (GY6) |
|
Starting System |
Electric start+kick start |
|
Bore&Stroke |
56.5x57.8mm{200cc:63.5x62.2mm} |
|
Stroke |
4 stroke and ignition:CDI |
|
Cooling |
water cooled |
|
Max.power Output |
6.8kw/(7500r/min){200cc: 10.2kw/(7500r/min)} |
|
Maximum Torque |
11kw/(5500r/min){200cc: 14N.m/(6000r/min)} |
|
2.Transmission |
|
|
Gear shift |
4 forward,neutral and 1 reverse gear |
|
Drive |
shaft |
|
3.Tires&Wheels |
|
|
Front Wheel |
23*7-10 (12 inch alloy rim) |
|
Rear Wheel |
22*10-10 (12 inch alloy rim) |
|
4.Brakes |
|
|
Type |
Front Double hydraulic drum brakes (Hand operated),Rear Hydraulic disc brake |
|
Fuel Capacity |
8L,plastic tank |
|
5.Suspension |
|
|
Front |
Independent double-wishbone with double airbag shocks |
|
Rear |
Swing arm with single airbag shock |
|
6.Dimensions |
|
|
LengthxWidthxHeight(mm) |
1,710x1,200x1,130mm |
|
Ground clearance |
270mm |
|
Maximum Rider Weight |
190kg |
|
Gross/Net Weight |
200/190kg |
|
Front Tread |
800mm |
|
Seat to Footstep(mm) |
450mm |
|
Rear Tread |
760mm |
|
Wheelbase(mm) |
1200mm |
|
Seat Height(mm) |
850mm |
|
7.Package |
|
|
Carton Size |
1500*830*810mm |
|
Container |
20PCS/42PCS/63PCS |
Carton Size:1500*830*810 mm
Container:20pcs/42pcs/63pcs
( steel +box per carton,or as per your requested.)
Shipping:
By express as DHL or FedEx,or by sea for sample or mass products,and can as your requested
Usually send out within 5-7days; The time for mass production relys on the stock, usually 7-20days
