Quick Details
-
Model Number:
-
GK-M2-7
-
Weight:
-
68.5 kg
-
Aspect Ratio:
-
2000:1
-
Packing Dimension:
-
1641*1180*165 mm
-
Product Dimension:
-
1486.1*888.6*119.9 mm
-
Product name:
-
Interactive Whiteboard Interactive Smart Board For Meeting
-
Operating system:
-
Android+win7/10 Optional
-
Touch Type:
-
Infrared Touch 20 Points
-
Screen Type:
-
65 Inch LCD Screen
-
Brightness:
-
450-500cd/㎡
-
Surface:
-
Wiredrawing Aluminum+Tempered glass
-
Panel brand:
-
Brand New ( A Grade) BOE / CSOT / LG Optional
-
Application:
-
Classroom, Training Room, Meeting Room, Home etc..
-
Visual Angle (horizontal/vertical):
-
178°/178°
-
Warranty:
-
1 Year
Quick Details
-
Panel Size:
-
65inches
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GeeKing / Custom
-
Model Number:
-
GK-M2-7
-
Weight:
-
68.5 kg
-
Aspect Ratio:
-
2000:1
-
Packing Dimension:
-
1641*1180*165 mm
-
Product Dimension:
-
1486.1*888.6*119.9 mm
-
Product name:
-
Interactive Whiteboard Interactive Smart Board For Meeting
-
Operating system:
-
Android+win7/10 Optional
-
Touch Type:
-
Infrared Touch 20 Points
-
Screen Type:
-
65 Inch LCD Screen
-
Brightness:
-
450-500cd/㎡
-
Surface:
-
Wiredrawing Aluminum+Tempered glass
-
Panel brand:
-
Brand New ( A Grade) BOE / CSOT / LG Optional
-
Application:
-
Classroom, Training Room, Meeting Room, Home etc..
-
Visual Angle (horizontal/vertical):
-
178°/178°
-
Warranty:
-
1 Year
Why Choose Us
- Our Advantages -
1.
Strong OEM/ODM manufacturing capability:
8 Years Focus On Commercial Display One-stop Solutions,
14,000㎡ Factory Floorspace;
Production
capacity
of 500 products per day;
2
.
Customized
MOQ=1
pcs:
From simple logo and packaging customization to complex product hardware and software solution design;
3.
Top 1
in large size shipments in China:
For products with the size of 100 inches and above, we have great advantages, and the shipment volume is
among the top three in China;
4.
Two times
aging test:
During the production process, aging at 40 ℃ for 2 hour, and aging at room temperature for 4-8 hours after
offline.
We don't make brand, we make your brand better.
Product Description
Customized All In One 65 75 86 98 Inch Electronic Whiteboard Interactive Board Smart Digital Board For Office Meeting /
Custom Factory Price 65 75 86 98 100 105 110 Inch All In One Interactive Flat Panel Digital Whiteboard Electronic Smart Board For Conference
Interactive board:
Ultra high 4K resolution，Sensitive 20 points IR touch，Built in professional whiteboard software，Professional Anti-Glare glass.
Dual System:
Open ecosystem allows you to choose whichever apps are best for you and your organization. Interactive board have dual systems, Android 11 and windows 10, you can use existing Zoom, Google Meet, Microsoft Teams, Webex and other popular 3rd party video conferencing meetings .
New 65 75 86 98 Inch Display Touch Screen Pizarra Digital Smart Interactive White Board Flat Panel Whiteboard For Class Teaching/
New ODM Cheap Interact Display Digital Smart Board 20 Points Infrared Smart LCD Touch Screen Interactive White board For Meeting
Wireless Share:
Smart board supports phone pc tablet up to 4 users to screencast simultaneously via Airplay and Eshare, or by connecting in via H-DMI. With your screen cast, you can annotate as needed, share via video conferencing, or screenshots.Supports multi-person and multi-device editing and sharing on the 4K UHD interactive board in real-time.
|
Size (inch)
|
Area (
㎡
)
|
Persons
|
L*W*H (mm)
|
|
65
|
20-30
|
20
|
1486.08*901.26*88.9
|
|
75
|
30-40
|
35
|
1708*1026*89.1
|
|
86
|
50-80
|
50
|
1954.44*1165.21*89.1
|
|
98
|
60-120
|
100
|
22.18.24*1318.1*100.81
|
Specification
|
Product Name
|
All In One Interactive Smart Whiteboard For Conference & Education
|
|
|
Dual System
|
|
|
|
Windows 10 OS
|
Intel core i3/i5/i7 option,
|
|
|
|
Memory 4G/8G/16G option
|
|
|
|
Hard Disk: 128G/256G/512G/1T option
|
|
|
Android OS
|
Quad core, 3G RAM, 32G ROM, Android 8.0/9.0 version
|
|
|
LCD Panel
|
|
|
|
Size
|
65 inch / 75 inch / 85 inch / 98 inch Available
|
|
|
Panel Brand
|
LG、BOE、AU (gauge A screen)
|
|
|
type
|
TFT-LCD S-PVA
|
|
|
Resolution
|
3840 × 2160 (UHD) @60hz, 4K UHD screen
|
|
|
Brightness
|
450 cd/m²
|
|
|
Ratio contrast
|
2000:1
|
|
|
Visual Angle (horizontal/vertical)
|
178°/178°
|
|
|
Response time
|
8ms
|
|
|
Visual area(mm)
|
1649.7(W)×928(H) mm
|
|
|
Color gamut (NTSC)
|
72%
|
|
|
Backlight
|
WLED
|
|
|
display scale
|
16:9
|
|
|
Response time
|
＜8ms
|
|
|
Life
|
>60000H
|
|
|
Infrared touch characteristic
|
|
|
|
Touch the specifications
|
Infrared touch frame
|
|
|
glass
|
4mm tempered glass
|
|
|
Glass transmittance
|
> 88% (higher transmittance depends on glass surface treatment technology such as AR/AG)
|
|
|
Object induction number (IR)
|
Touch at 20
|
|
|
Number of infrared induction lines (W D)
|
32767 × 32767
|
|
|
Positional accuracy
|
More than 90% of the touch area is 2mm
|
|
|
The interface definition
|
USB 2.0(Full speed)
|
|
|
Touch the strength
|
Zero pressure touch
|
|
|
The light resistance
|
It has light resistance
|
|
|
Induction life
|
6 million times
|
|
|
The response time
|
＜8ms
|
|
|
The power supply mode
|
Full duplex usb-powered DC +5V up to 500mA
|
|
|
Switching power supply
|
|
|
|
Power consumption (typical value)
|
AC100-240V~(+/-10%),50/60Hz
|
|
|
Standby power consumption
|
270W
|
|
|
The power interface
|
1W
|
|
|
Switching power supply
|
European standard 220V two - phase three - wire system
|
|
|
Mechanical specification parameters
|
|
|
|
The net weight
|
52kg
|
|
|
Gross weight
|
65.5kg
|
|
|
Bare machine outline size (W x D x H)
|
1486.1×119.9×888.6 mm
|
|
|
Package size (W x D x H)
|
1641×1180×165 mm
|
|
|
Shell material (face frame/back shell)
|
Plastic/Sheet metal
|
|
|
Shell color (face frame/back shell)
|
black
|
|
|
To protect the glass
|
4mm toughened glass/level 7 earthquake resistant
|
|
|
Type of installation
|
Supports/wall hangers
|
|
|
The cooling way
|
Temperature-controlled fan dissipates heat
|
|
|
The environment
|
|
|
|
Working temperature
|
0℃~50℃
|
|
|
Working humidity
|
20%~80%(No condensation)
|
|
|
Storage temperature
|
-20℃~60℃
|
|
|
Store humidity
|
10%~90%(No condensation)
|
|
|
Display mode
|
S-ips, often black display, transmission
|
|
|
Maximum service time (hours/day)
|
24 hours
|
|
|
Features
|
|
|
|
The speaker
|
2×8Ω/5W(built in)
|
|
|
Support for input mode
|
Stylus writes keyboard
|
|
|
The attachment
|
|
|
|
The user manual
|
Manual, warranty card, certificate of conformity
|
|
|
cable
|
The power cord
|
|
|
Others (optional accessories)
|
Remote control, base/bracket, WiFi
|
|
OEM Interactive Whiteboard Scuola Pizarron Infantil Digital Led 65 Inches Smart 4k Uhd E Board Conference Interactive Whiteboard
/
Wholesale Customized Pizarra Interactiva 4K Multi Points Infrared Touch Panel Interactive White board Smart Whiteboard For School Teaching
