- Product Details
- {{item.text}}
Quick Details
-
Counting direction:
-
Two-way counting
-
Accuracy rate:
-
80%-85%
-
PC data viewing:
-
View based on web-side data
-
Network access:
-
Wi-Fi (802.11G)Support wired network, RJ45
-
Installation method:
-
Wall-mounted, ceiling-mounted
-
lens:
-
2.8mm,1/2.5CCD,720 P
-
Filters:
-
Infrared filter
-
Installation height:
-
2.5 M-6M
-
Passenger flow inspection range:
-
2.5-3.2 meters
-
Power supply mode:
-
DC12V,1A
Quick Details
-
Brand Name:
-
FOORIR
-
Place of Origin:
-
Sichuan, China
-
Model Number:
-
HX-CCD10
-
Counting direction:
-
Two-way counting
-
Accuracy rate:
-
80%-85%
-
PC data viewing:
-
View based on web-side data
-
Network access:
-
Wi-Fi (802.11G)Support wired network, RJ45
-
Installation method:
-
Wall-mounted, ceiling-mounted
-
lens:
-
2.8mm,1/2.5CCD,720 P
-
Filters:
-
Infrared filter
-
Installation height:
-
2.5 M-6M
-
Passenger flow inspection range:
-
2.5-3.2 meters
-
Power supply mode:
-
DC12V,1A
|
Name
|
Illustrate
|
|
Recognition algorithm
|
Based on the principles of intelligent video analysis
|
|
|
Detect heads and shoulders and track travel
|
|
Counting direction
|
Two-way counting (simultaneous identification of entry and exit)
|
|
Accuracy rate
|
Passenger flow statistics accuracy 90%-95%
|
|
Data upload
|
Every 1 minute, one piece of data is uploaded to the cloud platform
|
|
Disconnect from the network and
resume the transmission |
Support
|
|
Data caching
|
The maximum in-machine data cache is 30 days, which is overwritten by a loop
|
|
Platform-side connection method
|
Proactive on-device discovery and connectivity to platforms
(including private cloud platforms) |
|
PC data viewing
|
View based on web-side data
|
|
Network access
|
Support wireless Wi-Fi (802.11G)
|
|
|
Support wired network, RJ45 interface
|
|
Installation method
|
Wall-mounted, ceiling-mounted
|
|
lens
|
2.8mm，1/2.5CCD，720 P
|
|
Filters
|
Infrared filter
|
|
Installation height
|
Minimum installation height 2.5 meters;
Maximum installation height 6 meters; |
|
Passenger flow
inspection range |
The width of each equipment covering the ground: 2.5-3.2 meters
(according to different installation heights); Adjustable coverage width; |
|
Wifi configure method
|
Use Smart Link mode to configure the operation of WiFi;
|
|
Remote parameter
configuration |
Device parameter configuration through the cloud platform is
supported |
|
Remote upgrade
|
Support firmware upgrade of devices through cloud platform
|
|
Power supply mode
|
DC12V，1A
|
|
Product size
|
Maximum diameter 111mm，Thickness 33mm
|
Three-point detection
The deep learning algorithm is used to recognize the three points of head and shoulders, automatically analyze the collected video image sequence, judge the walking direction of the human target, and judge the "in" or "out".
Wider coverage
Large field of view, covering up to 3.2 meters wide.
Optional installation height: 2.5-6 meters, adjustable coverage width
Cloud platform management system
The equipment returns data once a minute, directly transmits the statistical results to the cloud platform, only transmits passenger flow data, and occupies low bandwidth.
.
Installation method
This device needs to be mounted on the top and shoot vertically downwards to get a video at a downward angle.
Customer visiting
Customer evaluation
FAQ
1:Do you have certifications for your product?
A: yes, we have certifications of CE, FCC, ROHS, and so on.
2:Can accept OEM?
A: Yes, we can accept customize products according to your requirement.
3: How long will it take to prepare the products and how long will the warranty be?
A: Ordinary express takes 3-6 days, air express takes 2-3 days, sea takes 20-30 days, the warranty period of each product is different, you can contact us to negotiate.
4: Whether remote access devices are support?
A: sorry, the device does not support remote access.
5: Can I use my own server?
A: Yes, we can provide data upload protocol for you to connect the device with your server.
6: What are the computer operation and system requirements?
A: Operate our debugging software client needwin7, win8, win10, win11.
