Quick Details
-
Brand Name:
-
muwang
-
Model Number:
-
WL180692P
-
OEM & ODM:
-
Yes
-
Nominal Diameter:
-
472mm
-
Nominal impedance:
-
7.2 OHM
-
Max Power Input:
-
2600W
-
Frequency Range:
-
21-800HZ
-
Sensitivity:
-
87db
-
Voice Coil Diameter:
-
99.5mm
-
Magnet Diameter:
-
220*2mm
-
BasketIron:
-
aluminum
-
Winding Depth:
-
50mm
Quick Details
-
Power:
-
2600W
-
Frequency Range (Hz):
-
21-800HZ
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
muwang
-
Model Number:
-
WL180692P
-
OEM & ODM:
-
Yes
-
Nominal Diameter:
-
472mm
-
Nominal impedance:
-
7.2 OHM
-
Max Power Input:
-
2600W
-
Frequency Range:
-
21-800HZ
-
Sensitivity:
-
87db
-
Voice Coil Diameter:
-
99.5mm
-
Magnet Diameter:
-
220*2mm
-
BasketIron:
-
aluminum
-
Winding Depth:
-
50mm
Product Parameter
| Model | WL180692P |
| Product Name |
18 inch sub woofer speaker |
| General Specifications |
| Nominal Diameter | 472 mm |
| Resonate Frequency fs |
21Hz |
| Resonate Frequency Range |
21-800HZ |
| Sensitivity | 87db |
| Nominal Impedance | 7.2 0 HM |
| Shortterm Maximum Power | 2600W |
| Magnet Diameter | 220*2mm |
| Voice Coil Diameter | 99.5mm |
| Mechanical Quality Factor ,Qms | 3.343 |
| Total Quality Factor,Qts |
0.492 |
| Equivalen Air Volume to Cms,Vas | 211L |
| Physical Information |
| Basket(Frame) | aluminum |
| BL | 40.7T.m |
| Voice Coil Wire | CCAW |
| Voice Coil Bobbin |
Aluminium(ASV) |
| Magnet |
Ferrite |
