Quick Details
-
Grade:
-
carbon steel plate, Q235B,Q345B,SS400,S275JR,S235JR,S355JR,A36
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Shunyun
-
Application:
-
Structural Plate
-
Width:
-
400-2500mm
-
Length:
-
1000-12000mm
-
Surface treatment:
-
galvanized ,Coated,or as requested
-
Service:
-
OEM/ODM
-
Certification:
-
ISO/BV
-
Price:
-
factory lower price
-
Size:
-
customized
-
Quality:
-
high
-
MOQ:
-
1 Ton
Quick Details
-
Type:
-
Steel Sheet
-
Thickness:
-
0.3-100mm
-
Standard:
-
AiSi
-
Grade:
-
carbon steel plate, Q235B,Q345B,SS400,S275JR,S235JR,S355JR,A36
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Shunyun
-
Application:
-
Structural Plate
-
Width:
-
400-2500mm
-
Length:
-
1000-12000mm
-
Surface treatment:
-
galvanized ,Coated,or as requested
-
Service:
-
OEM/ODM
-
Certification:
-
ISO/BV
-
Price:
-
factory lower price
-
Size:
-
customized
-
Quality:
-
high
-
MOQ:
-
1 Ton
| Hot Rolled Structural steel Mild Carbon Steel Plate | ||||
| Steel type | Carried standard | Steel grade | Level | Thickness scope |
| Carbon Structural steel | GB/T 700-2006 | Q195 | - | 1.5~20 |
| Q215 | A,B | 1.5~20 | ||
| Q235 | A,B,C,D | 1.5~300 | ||
| Q275 | ||||
| EN 100025-2:2004 | S235 | JR,J0,J2,K2 | 1.5~300 | |
| S275 | 1.5~300 | |||
| S355 | 3.0~300 | |||
| ASTM A36/A36M-13 | A36 | - | 1.5~300 | |
| JIS 3101-2010 | SS330 | - | 1.5~300 | |
| SS400 | - | 1.5~300 | ||
| SS490 | - | 3.0~300 | ||
| SS540 | - | 3.0~300 | ||
| GB/T 710-2008 | 08,08Al,10,15, | - | 1.5~200 | |
| 20,30,35 | ||||
| GB/T 711-2008 | 08F,08,10F,20, | - | 1.5~120 | |
| 20Mn,60Mn | ||||
| ASTM A568/A568M-13 | SAE1006,SAE1008 | - | 1.5~300 | |
| Low alloy structural steel | ASTM A568/A568M-13 | Q345 | A,B,C,D,E | 3.0~300 |
| Q390 | A,B,C,D,E | 4.0~300 | ||
| Q420 | ||||
| Q460 | C,D,E | 6.0~300 | ||
| Q500 | ||||
| Q550 | ||||
| JIS G3106-2008 | SM400 | A,B,C | 1.5~300 | |
| SM490 | A,B,C | 3.0~300 | ||
| SM520 | B,C | 6~300 | ||
| SM570 | - | |||
| ASTM A572/A572M-13 | Gr42 | - | 1.5~300 | |
| Gr50 | - | 3.0~300 | ||
| Gr55 | - | 4.0~300 | ||
| Gr60 | - | 4.0~300 | ||
| Gr65 | - | 6.0~300 | ||
| Steel type | Carried standard | Steel grade | Delivery Status | Thickness scope |
|
Ship building structural steel plate |
ABS,BV,CCS, | A,B | AR | 6~40 |
| DNV, | ||||
| GL, KR,LR, | NR | 40~60 | ||
| NK RINA, | D | TMCP | 6~60 | |
| RS Specifications of ten | E | TMCP | 6~60 | |
| classification society | AH32 AH36 AH40 | TMCP | 6~60 | |
| DH32 DH36.DH40 | ||||
| EH32,EH36EH40 | ||||
| FH32 FH36.FH40 | ||||
| Finished | Thickness (MM)=T | Width (MM)=W | ||
| Hot rolled | 1.8~6 | 1250 | ||
| 3~20 | 1500 | |||
| 6~18 | 1800 | |||
| 18~300 | 2000,2200,2400,2500 | |||
| Cold rolled | 0.8~3 | 1250, 1500 | ||
| Galvanized | 0.8~3 | 1250, 1500 | ||
