- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
140x140x140cm
-
Power (kW):
-
6kw
-
Weight (KG):
-
380 kg
-
Panel Feed Speed(m/min):
-
22m/min
-
Model Number::
-
edge banding machine
-
Voltage::
-
380V/220V
-
Power(W)::
-
6000W
-
Dimension(L*W*H)::
-
140x140x140cm
-
Weight::
-
380kg
-
Feeding Speed::
-
0-22m/min
-
Edge Thickness::
-
0.4~3mm
-
Model:
-
MY11
-
Panel Thickness::
-
14-70mm
-
Applicable Industries::
-
Home Use, woodworking machinery
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Aucox
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
140x140x140cm
-
Power (kW):
-
6kw
-
Weight (KG):
-
380 kg
-
Panel Feed Speed(m/min):
-
22m/min
-
Model Number::
-
edge banding machine
-
Voltage::
-
380V/220V
-
Power(W)::
-
6000W
-
Dimension(L*W*H)::
-
140x140x140cm
-
Weight::
-
380kg
-
Feeding Speed::
-
0-22m/min
-
Edge Thickness::
-
0.4~3mm
-
Model:
-
MY11
-
Panel Thickness::
-
14-70mm
-
Applicable Industries::
-
Home Use, woodworking machinery
Products Description
The WOODFUNG MY11 is a semi-automatic edge bander with universal trimmer, ideal for machining profiled (concave and/or convex), straight or large boards.
The Woodfung MY11 Edge Bander is a semi-automatic entry-level profile edger with a movable support arm capable of handling panels of different sizes.
The new 10-inch touchscreen is more powerful and intuitive. The new base design ensures greater machine stability. New software with internal library and smart application: changing the glue type also automatically changes the mapping.
With the Woodfung MY11 edgebander, you can perform edgebanding and trimming operations at the same time. An extremely versatile machine, it requires minimal investment and represents an efficient end-finishing for laser machining centers. This is a particularly intelligent machine, essential for those who have to respond to different demands every day while maintaining high quality standards.
|
Model
|
MY11
|
Functions
|
Gluing、edge band heating、automatic end cutting、trimming、scraping、glue cleaning
|
|
Edge banding thickness
|
0.5~3mm
|
Speed
|
0-37cm/s
|
|
Banding type
|
double glue sided
|
Glue pot need
|
2600ml
|
|
External vacuum
|
φ150mm
|
Trimming motor speed
|
24000r/min
|
|
Edge banding width
|
14-70mm
|
Air pressure
|
0.6-0.8Mpa
|
|
Arm extension length
|
209cm
|
Min. inner arc radius
|
20mm
|
|
Operation temperature
|
110~210
|
Suction cup diameter
|
14*14/30*30cm
|
|
Machine size
|
120x55x110cm
|
Types of edgebands
|
PVC、ABS、melamine etc.
|
|
N.W/G.W
|
380kg/430kg
|
Total power
|
6000W
|
|
Voltage
|
380V/220V
|
Frequency
|
50hz/60hz
|
Details Images
Recommend Products
FAQ
Q1: What is the warranty for the machine?
For our woodworking machine, we have 18months warranty.
Q2:Can I choose the Plug?
Yes,we have 220V/440V/380V for your choice,and 1phase,3phase,50hz and 60hz
Q3.What is your lead time after i pay?
Normally,we have stock for the machine,only customized for voltage ,about 7days or 15days.
Q4:How long will i get the machine after i pay?
The machine will deliver by sea to your port.about 20~55days arrival.
Q5:Is it OK to print my logo on the product?
Yes.Please inform us formally before our production and confirm the design firstly for the mass production.
Q6:It is my first time to purchase goods from china,how do i do?
Do not worry,Aucox/Woodfung has 10years export experience to all over the world,
also has professional sales team,we also have agent in Russia,Algeria,Pakistan,Peru,Vietnam,etc.
Q7:How to pack the machine?
we use wooden box to packge the machine to protect them to be safe
Q8.I do not know chinese,will the operation panel in english or spanish or other?
Yes,all our machine are with Chinese and English,If you want only English or Spanish or other,
we also can customize to you,but lead time will be a little longer.
For our woodworking machine, we have 18months warranty.
Q2:Can I choose the Plug?
Yes,we have 220V/440V/380V for your choice,and 1phase,3phase,50hz and 60hz
Q3.What is your lead time after i pay?
Normally,we have stock for the machine,only customized for voltage ,about 7days or 15days.
Q4:How long will i get the machine after i pay?
The machine will deliver by sea to your port.about 20~55days arrival.
Q5:Is it OK to print my logo on the product?
Yes.Please inform us formally before our production and confirm the design firstly for the mass production.
Q6:It is my first time to purchase goods from china,how do i do?
Do not worry,Aucox/Woodfung has 10years export experience to all over the world,
also has professional sales team,we also have agent in Russia,Algeria,Pakistan,Peru,Vietnam,etc.
Q7:How to pack the machine?
we use wooden box to packge the machine to protect them to be safe
Q8.I do not know chinese,will the operation panel in english or spanish or other?
Yes,all our machine are with Chinese and English,If you want only English or Spanish or other,
we also can customize to you,but lead time will be a little longer.
Warranty
1. AUCOX Provide 15 months warranty for all customers.
2. During warranty, we provide free normal spare parts once machine has probem.
3. AUCOX will solve customer's machine problem within 24 hours from the time problem raised.
4. AUCOX has enough spare parts for machines.
5. When machine out of warranty, AUCOX still provide free technical support and spare parts charged to customers.
ATTENTION:all machines in the website is always improving,if there is a little changed,no care.it is not influence the
usage,better quality for always improvement.
2. During warranty, we provide free normal spare parts once machine has probem.
3. AUCOX will solve customer's machine problem within 24 hours from the time problem raised.
4. AUCOX has enough spare parts for machines.
5. When machine out of warranty, AUCOX still provide free technical support and spare parts charged to customers.
ATTENTION:all machines in the website is always improving,if there is a little changed,no care.it is not influence the
usage,better quality for always improvement.
