Quick Details
-
2.4G Wi-Fi Transmission Rate:
-
600Mbps
-
Type:
-
Wireless
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
WIFI:
-
2.4&5 GHz, WIFI 4T4R,802.11 a/b/g/n/ac
-
BB Chipset:
-
Qualcomm MDM9250 / SDX20/24/55
-
AP+WIFI Chipset:
-
MT7621DAT+MT7603E+MT7613BEN
-
power consumption:
-
<15W
-
Power Voltage:
-
DC12V/2A
-
VPN Pass Through:
-
PPTP/L2TP/IPSec
-
SIM Lock:
-
Support
-
TR069:
-
Support
Quick Details
-
Max. LAN Data Rate:
-
1000Mbps
-
With Modem Function:
-
NO
-
Wi-Fi Supported Frequency:
-
2.4G & 5G
-
2.4G Wi-Fi Transmission Rate:
-
600Mbps
-
Type:
-
Wireless
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
WIFI:
-
2.4&5 GHz, WIFI 4T4R,802.11 a/b/g/n/ac
-
BB Chipset:
-
Qualcomm MDM9250 / SDX20/24/55
-
AP+WIFI Chipset:
-
MT7621DAT+MT7603E+MT7613BEN
-
power consumption:
-
<15W
-
Power Voltage:
-
DC12V/2A
-
VPN Pass Through:
-
PPTP/L2TP/IPSec
-
SIM Lock:
-
Support
-
TR069:
-
Support
| C5R+B50+A2:D12+A2:D29+B50+A2:D12+A2:D4+A2:D12 | ||||||||||||||||
| Category | Feature & specification | Description | Customer Comments | |||||||||||||
| Basical Information | Model Name | C5R400 | ||||||||||||||
| Form Factor | CPE | |||||||||||||||
| Dimension | 151mm*150mm*48mm | |||||||||||||||
| Weight | <500g | |||||||||||||||
| Color | white/Black | |||||||||||||||
| ID&MD Model |
|
|||||||||||||||
| Air Interface | Technical Standard | Compatible with FDD-LTE,TDD-LTE, WCDMA,GSM 802.11 b/g/n/ac | ||||||||||||||
| Frequency | 5G:SA/NSA N1/2/3/4/5/7/8/12/13/14/17/18/18/25/26/28/29/30/38/39/40/41/66/71 4G:FDD Band1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71(optional) TDD Band 38/39/40/41/42/43/46/48(optional) 3G:WCDMA: 850/1800/1900/2100/900MHz Can switch module to cover more frequencies combination *B29/32/46 support Rx only and are only for secondary component carrier | |||||||||||||||
| WIFI | 2.4&5 GHz, WIFI 4T4R,802.11 a/b/g/n/ac | |||||||||||||||
| Performance | Maximum Data Throughput | 4G: Category 4/6/9/12/16 (DL:150/300/450/600/1000Mbps,(Support up to DL 5 x CA) upload:50/150Mbps) 5G NSA: Max. 2.5 Gbps (DL)/650 Mbps (upload) SA: Max. 2.1 Gbps (DL)/450 Mbps (upload) | ||||||||||||||
| Hardware | Receive Diversity | Support Receive Diversity | ||||||||||||||
| MIMO | Support 4×4MIMO in DL direction,Output Max Power:21~23dBm,External Antenna 6dBi(optional) | |||||||||||||||
| BB Chipset | Qualcomm MDM9250 / SDX20/24/55 | |||||||||||||||
| AP+WIFI Chipset | MT7621DAT+MT7603E+MT7613BEN | |||||||||||||||
| Memory | RAM:128Mb , ROM:1024Mb | |||||||||||||||
| power consumption | <15W | |||||||||||||||
| Power Voltage | DC12V/2A | |||||||||||||||
| USIM/SIM | 2FF SIM card support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card;internal push-push SIM slot | |||||||||||||||
| LED | SYS, LTE, SIGNAL, WiFi, WAN,LAN,SIM | |||||||||||||||
| USB | 1 USB 2.0 port support Share | |||||||||||||||
| Antenna | 2 x LTE 2x2 MiMo,4*LTE 4*4 MiMo,8*LTE,8*8 MiMo 2 x WIFI (2.4 + 5G) 4*4 MIMO Output Power 19dBm , Antenna (3dBi) | |||||||||||||||
| Buttons | POWER,Reset | |||||||||||||||
| Ethernet | 4 LAN ports or 1WAN+3LAN, 10BaseT/100Base/1000Base automatic adaptive port | |||||||||||||||
| Reset | Pin hole | |||||||||||||||
| ESD | ESD Protection circuit;Contact±4KV,Air±8KV | |||||||||||||||
| Software | SW Update | TR069 & Local Update | ||||||||||||||
| WIFI Mode | AP Only | |||||||||||||||
| WIFI Security | 64/128 bit WEP,WPA-PSK/WPA2-PSK | |||||||||||||||
| SMS | ||||||||||||||||
| USB Function | File and printer sharing | |||||||||||||||
| Voice | Not Support | |||||||||||||||
| AGPS | Not Support | |||||||||||||||
| IPv4 | Support IPv4 | |||||||||||||||
| IPv6 | Support IPv6 | |||||||||||||||
| Firewall | Mac/IP address filter, Port forwarding, WiFi Black/Whilte list ALG: SIP(must)/RSTP(optional) FTP(optional) | |||||||||||||||
| Data Statistics | Support | |||||||||||||||
| VPN Pass Through | PPTP/L2TP/IPSec | |||||||||||||||
| SIM Lock | Support | |||||||||||||||
| TR069 | Support; | |||||||||||||||
| Fota | Support; | |||||||||||||||
| SNTP | Support | |||||||||||||||
| DOS ATTACK | Support | |||||||||||||||
| DMZ | Support | |||||||||||||||
| HTTP | Support | |||||||||||||||
| HTTPS | Support | |||||||||||||||
| Certification | FCC | Depends on customization, cost related | ||||||||||||||
| Environment | Operating Temperature | Normal:-15°C to +55°C; | ||||||||||||||
| Storage Temperature | -20° C to +85° C | |||||||||||||||
| Humidity | 5%~ 90% | |||||||||||||||
