- Product Details
- {{item.text}}
Quick Details
-
Power:
-
7.6KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JM
-
Maximum Digging Height:
-
2500MM
-
Maximum Digging Depth:
-
1600MM
-
Machine Weight:
-
980 kg
-
Max Digging Radius:
-
1490MM
-
Rated Speed:
-
1.2KM/H
-
Marketing Type:
-
Classic Product
-
Easy Fuel:
-
Yes
-
Optional Engine:
-
JAPAN KUBTA
-
Swing Boom:
-
Optional
-
Adjustable Tracks:
-
Optional
-
Cabin:
-
Optional
-
Full Galvanized Parts:
-
Optional
-
Customized Color:
-
Yes
-
Customized LOGO:
-
Yes
-
USA EPA Certification:
-
Yes
-
Europe EURO5 Emissoin/CE:
-
Yes
Quick Details
-
Operating Weight:
-
1Ton
-
Bucket capacity:
-
0.025cbm
-
Engine Brand:
-
KOOP/CHANGCHAI
-
Power:
-
7.6KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JM
-
Maximum Digging Height:
-
2500MM
-
Maximum Digging Depth:
-
1600MM
-
Machine Weight:
-
980 kg
-
Max Digging Radius:
-
1490MM
-
Rated Speed:
-
1.2KM/H
-
Marketing Type:
-
Classic Product
-
Easy Fuel:
-
Yes
-
Optional Engine:
-
JAPAN KUBTA
-
Swing Boom:
-
Optional
-
Adjustable Tracks:
-
Optional
-
Cabin:
-
Optional
-
Full Galvanized Parts:
-
Optional
-
Customized Color:
-
Yes
-
Customized LOGO:
-
Yes
-
USA EPA Certification:
-
Yes
-
Europe EURO5 Emissoin/CE:
-
Yes
1. Product Parameters
| Main Dimentions | |
| Operating Weight | 980kg |
| Bucket Capacity | 0.025cbm/120kg |
| Bucket Width | 380 |
| Boom Length | 1350 |
| Arm Length | 700 |
| Travel Speed | 3.5M/H |
| Overall Length | 2550 |
| Overall Width | 930 |
| Overall Height | 1350 |
| Superstructure width | 930 |
| Counterweight ground clerance | 400 |
| Total track length | 1200 |
| Track shoe width | 180 |
| Total track width | 930 |
| Min.Front Swing radius | 1800 |
| Dozer blade with | 930 |
| Max.Diiging radius | 2550 |
| Max.Digging Depth | 1600 |
| Max.Digging Height | 2500 |
| Max.Dumping Height | 1750 |
| Grade Ability | 35° |
| Ground Pressure | 25KPA |
| Bucket digging force | 800KN |
| Arm digging force | 600KN |
| Engine KOOP / KUBOTA | |
| Fuel consumption | 1.5-1.8L/H |
| Engine Oil | 5L |
| Engine brand | KOOP KD192 / KUBOTA D722 |
| Rated Power | 8.5kw / 11.8kw /2500r/min |
| Displacement | 1.216L/CC |
| Cylinders | 1 / 3 |
| Cooling type | Air–cooling / Water-cooling |
| PARTS | |
| Main pump | Gear pump - BEIFANG |
| Rated Pressure | 18MPA |
| Main pump Max.Flow | 6L/Min |
| Walking hydraulic motor type | BEIFANG China |
| Swing hydraulic motor | BEIFANG China |
| Auxiliary Piping for Hammer | YES |
| Fuel Tank | 11L |
