Quick Details
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
Customized Size
-
Weight:
-
200 KG
-
Product name:
-
cyclone
-
Application:
-
Mining Separation
-
Usage:
-
Classification
-
Sizing Size:
-
0.07~0.5mm
-
Material:
-
Alumina Ceramics&High Chromium Alloys&
-
Capacity:
-
70~2250t/h
-
Processed materials:
-
Separating Stones
-
Color:
-
Customized Making
-
Application Area:
-
Sieving Ores
-
Feature:
-
High Separation Efficiency
Quick Details
-
Production Capacity:
-
Varies
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
TSX
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
Customized Size
-
Weight:
-
200 KG
-
Product name:
-
cyclone
-
Application:
-
Mining Separation
-
Usage:
-
Classification
-
Sizing Size:
-
0.07~0.5mm
-
Material:
-
Alumina Ceramics&High Chromium Alloys&
-
Capacity:
-
70~2250t/h
-
Processed materials:
-
Separating Stones
-
Color:
-
Customized Making
-
Application Area:
-
Sieving Ores
-
Feature:
-
High Separation Efficiency
Product Description
Specification
|
Specification
|
Feeder Size (mm)
|
Feed Pressure(MPa)
|
Capacity (t/h)
|
Medium Circulation m³/h
|
|
AFX350
|
0.15-0.25
|
0.04-0.15
|
70-150
|
-
|
|
AFX380
|
0.15-0.30
|
0.04-0.15
|
80-170
|
-
|
|
AFX450
|
0.25-0.35
|
0.04-0.15
|
110-230
|
-
|
|
AFX500
|
0.25-0.50
|
0.04-0.15
|
200-300
|
-
|
|
AZX1500
|
≤135
|
0.10-0.20
|
140-300
|
1850-2250
|
|
AZX1450
|
≤120
|
0.10-0.20
|
100-220
|
1600-1850
|
|
AZX1300
|
≤115
|
0.10-0.20
|
70-160
|
1380-1600
|
|
AZX1150
|
≤105
|
0.10-0.18
|
45-100
|
1150-1300
|
|
AZX1000
|
≤100
|
0.10-0.15
|
40-100
|
1050-1150
|
|
AZX900
|
≤95
|
0.09-0.14
|
25-60
|
785-1050
|
|
AZX800
|
≤70
|
0.08-0.13
|
14-40
|
430-700
|
|
AZX710
|
≤65
|
0.08-0.12
|
8-25
|
360-430
|
|
AZX675
|
≤50
|
0.07-0.10
|
6-25
|
210-360
|
Details
FAQ
Q: Can I get some screen mesh samples? A: Yes, sample order is available for quality check and market test. But you have to pay
the sample cost and express cost.
Q: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.
Q: What's your payment terms?
A: We receive L/C, T/T.
Q: Installation
A: At the client’s request, TSX can provide installation Technicians to supervise and assist in the assembly and commissioning of
the equipment.
Q: What about Warranty? What will we do if the machine is broken down?
A: The warranty period for all of TSX’s structural and mechanical equipment is one year. The warranty period for all electric
motors is one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q: What should we need to do for if we want to get a best quotation?
A: If you want us recommend a suitable type for you; please let us know as follows:
1).the capacity (tons per hour)
2).output size
3).material type
Q: What could you help me to do for the business?
A: Many thanks for your trust, we can provide you with proposal chart for complete production lines, online guidance and operator
training according to your demands and the conditions of applied spot, we can help you choose the right equipment,flip-flop
vibrating screens, circular vibrating screens, sieve bends and centrifuges for classifying, de-sliming, drain & rinsing, and
sizing, used in coal washing and preparation plant sand so on .
Q: What are your after sales Service?
A: All equipment manufactured by TSX is of the highest standard and very rarely have our clients experienced any mechanical
problems. Should any problems occur, our team of Engineers and Technicians will respond within 12 hours of notice by the client.
Q: Delivery time
A: Standard delivery time for cyclone is 30 days from receipt of deposit.
the sample cost and express cost.
Q: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.
Q: What's your payment terms?
A: We receive L/C, T/T.
Q: Installation
A: At the client’s request, TSX can provide installation Technicians to supervise and assist in the assembly and commissioning of
the equipment.
Q: What about Warranty? What will we do if the machine is broken down?
A: The warranty period for all of TSX’s structural and mechanical equipment is one year. The warranty period for all electric
motors is one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q: What should we need to do for if we want to get a best quotation?
A: If you want us recommend a suitable type for you; please let us know as follows:
1).the capacity (tons per hour)
2).output size
3).material type
Q: What could you help me to do for the business?
A: Many thanks for your trust, we can provide you with proposal chart for complete production lines, online guidance and operator
training according to your demands and the conditions of applied spot, we can help you choose the right equipment,flip-flop
vibrating screens, circular vibrating screens, sieve bends and centrifuges for classifying, de-sliming, drain & rinsing, and
sizing, used in coal washing and preparation plant sand so on .
Q: What are your after sales Service?
A: All equipment manufactured by TSX is of the highest standard and very rarely have our clients experienced any mechanical
problems. Should any problems occur, our team of Engineers and Technicians will respond within 12 hours of notice by the client.
Q: Delivery time
A: Standard delivery time for cyclone is 30 days from receipt of deposit.
