Quick Details
-
Brand Name:
-
YUJIE
-
Model Number:
-
YJ-E098
-
Place of Origin:
-
Guangdong, China
-
Item:
-
100M POE switch
-
PoE Ports:
-
8-port with 802.3af/at PoE injector function
-
PoE Standard:
-
IEEE802.3af IEEE802.3at
-
Max transmission distance:
-
up to 250M
-
Vlan function:
-
support
-
EST Protection:
-
4KV
-
Dimension:
-
190*92*29 mm
-
Material:
-
PCBA + metal
-
Warranty:
-
12 Months
-
OEM & ODM:
-
Yes
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
1.25Gbps
-
Brand Name:
-
YUJIE
-
Model Number:
-
YJ-E098
-
Place of Origin:
-
Guangdong, China
-
Item:
-
100M POE switch
-
PoE Ports:
-
8-port with 802.3af/at PoE injector function
-
PoE Standard:
-
IEEE802.3af IEEE802.3at
-
Max transmission distance:
-
up to 250M
-
Vlan function:
-
support
-
EST Protection:
-
4KV
-
Dimension:
-
190*92*29 mm
-
Material:
-
PCBA + metal
-
Warranty:
-
12 Months
-
OEM & ODM:
-
Yes
Product Description
|
Product Name
|
100M POE switch
|
|
|
Hardware Specifications
|
|
|
|
Network connector
|
10 port RJ45 for 10/100BASE-TX, auto MDI/MDIX
|
|
|
PoE Inject Port
|
8-port with 802.3af/at PoE injector function (Port 1 to Port 8)
|
|
|
LED Display
|
System:
Power (Green) Per PoE port: PoE (Red/Blue, Port 1 to Port 8) LNK/ACT (Green, Port 1 to Port 10) |
|
|
Selectable operation mode
|
. Standard
· VLAN Extend |
|
|
Switch Architecture
|
Store and Forward
|
|
|
MAC Address Table
|
8K entries, automatic source address learning and aging
|
|
|
ESD Protection
|
Contact discharge of 4KV DC
Air discharge of 6KV DC |
|
|
Switch Fabric
|
2Gbps/non-blocking
|
|
|
Switch Throughput
|
1.48Mpps @64bytes
|
|
|
Maximum Packet Size
|
1522bytes
|
|
|
Flow Control
|
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex |
|
|
Power Requirements
|
52V DC, 2.3A or 52V1.25A
|
|
|
Power Consumption
|
Per port max. 30 watts
|
|
|
Dimension
|
190*92*29 mm
|
|
|
Power over Ethernet
|
|
|
|
PoE Standard
|
IEEE 802.3af Power over Ethernet/PSE
IEEE 802.3at Power over Ethernet Plus/PSE |
|
|
PoE Power Supply Type
|
End-span
|
|
|
Power Pin Assignment
|
1/2(+), 3/6(-),
|
|
|
PoE Power Output
|
Per Port max. 15.4 watts (IEEE 802.3af)
Per Port. max. 30 watts (IEEE 802.3at) |
|
|
PoE Power Budget
|
120 watts
|
|
|
Max. Number of Class 2 PDs
|
8
|
|
|
Max. Number of Class 3 PDs
|
4
|
|
|
Max. Number of Class 4 PDs
|
4
|
|
|
Standard Conformance
|
|
|
|
EMI Safety
|
FCC, CE
|
|
|
Standard Compliance
|
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX IEEE 802.3x Flow control and back pressure IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3az Energy Efficient Ethernet (EEE) |
|
|
Environment
|
Operating Temperature: 0 ℃-55 ℃
|
|
|
|
Relative Humidity: 10%-90%(non-condensing)
|
|
|
|
Storage Temperature: -0℃-80℃
|
|
|
|
Relative Humidity: 5%-90%(non-condensing)
|
|
Details Images
Related Products
Company Introduction
Shenzhen YUJIE Technology Co., Ltd
. is a professional manufacturer of Computer & Cell phone accessories. Our main products include: Network switches, Network cards, USB Hub, Data cable, audio converter and etc. All our products passed CE, FCC & RoHS.
Our factory was established in 2012, with sophisticated facilities and professional R&D team, we are good at OEM & ODM, so if you want do your own brand, we will be your reliable products provider.
Since we prepare stocks for each products, if you are a retailer or small wholesaler, work with us, we will support you with small MOQ & fast delivery.
Fell free to contact me for more details!
FAQ
Q1: Are you factory manufacturer or trade company?
A: We are a manufacturer. Our factory located in Dongguan.
Q2: Can I get a sample before order in bulk? What is your MOQ?
A: Yes, we support sample order. Our MOQ for stcoked products is 100pcs, and 1000pcs for OEM & ODM.
Q3: What is the lead time?
A: 3~5 working days for stocked products, and 15~30 days for customized items.
Q4: Can you do my logo on the products?
A: Sure, we can do your logo on both product & package.
Q5: What's your delivery term & payment terms?
A: We accept EXW, FOB, CFR, CIF, etc. You can choose the one which is the most convenient or cost effective for you. 100% in advance for sample order, 30% deposit and 70% balance for mass order.
Q6: How can we know the product quality?
A: We suggest you to order a sample, we guarantee the quality of bulk production will be same as sample.
Q7: After service and warranty?
A: We provide 1 year warranty, if you have any problems in the use of products, please contact us in time.
