Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
BEST
-
Dimension(L*W*H):
-
as your requests
-
Weight:
-
1 KG
-
Working Temperature Range:
-
1 - 40 ℃
-
Core Components:
-
heating wire
-
After-sales Service Provided:
-
Overseas third-party support available
-
Tube Diameter:
-
16mm-30mm
-
Application:
-
oil, water ,other liquid etc
-
Product name:
-
stainless steel immersion water tank tubular tube heating element
-
flange size:
-
115mm
Quick Details
-
Type:
-
Immersion Heater
-
Power Source:
-
Electric
-
Voltage:
-
380v 220v
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
BEST
-
Dimension(L*W*H):
-
as your requests
-
Weight:
-
1 KG
-
Working Temperature Range:
-
1 - 40 ℃
-
Core Components:
-
heating wire
-
After-sales Service Provided:
-
Overseas third-party support available
-
Tube Diameter:
-
16mm-30mm
-
Application:
-
oil, water ,other liquid etc
-
Product name:
-
stainless steel immersion water tank tubular tube heating element
-
flange size:
-
115mm
Product Description
| Reference Table for Water Quantity and Heating Tube Power | |||
| Water capacity | 3kw | 6kw | 9kw |
| 50L (100 pounds) | Around 1h/50℃ | Around 1h/100℃ | Around 40min/100℃ |
| 100L(200 pounds) | Around 1h/25℃ | Around 1h/50℃ | Around 1h/75℃ |
| 200L (400 pounds) | Around 1h/12℃ | Around 1h/25℃ | Around 1h/38℃ |
| 300L (600 pounds) | Suggest higher power | Around 1h/17℃ | Around 1h/25℃ |
| 500L (1000 pounds) | Suggest higher power | Around 1h/10℃ | Around 1h/15℃ |
| voltage power | tube length | Heating pipeline diameter | wire length | Combination form |
| 220v 3kw | 350mm | 2 lines, 2.5 square meters |
Total length of 3m, hose 2.5m |
3 U-shaped tubes |
| 220v 6kw | 400mm | 2 lines, 4 square meters | ||
| 220v 9kw | 450mm | 2 lines, 6 square meters | ||
| 380v 6kw | 400mm | 3 lines, 2.5 square meters | ||
| 380v 9kw | 450mm | 3 lines,4 square meters | ||
| 380v 12kw | 500mm | 3 lines, 4 square meters | ||
| 380v 15kw | 600mm | 3 lines, 6 square meters | ||
| 380v 18kw | 700mm | 3 lines, 6 square meters | ||
| 380v 20kw | 800mm | 3 lines, 6 square meters | ||
| 380v 25kw | 1000mm | 3 lines, 10 square meters |
Product advantages
1:Fully sealed full welding process
2:Only conducting heat but not conducting electricity
3:High power and rapid heating
4:Service life up to 3-5 years
5:Suitable for heating water tanks at sub zero temperatures
2:Only conducting heat but not conducting electricity
3:High power and rapid heating
4:Service life up to 3-5 years
5:Suitable for heating water tanks at sub zero temperatures
