Quick Details
-
Power:
-
14/2200 rpm
-
Place of Origin:
-
Shandong, China
-
Maximum Digging Height:
-
3880MM
-
Maximum Digging Depth:
-
2550MM
-
Machine Weight:
-
2500 kg
-
Marketing Type:
-
New Product 2024
-
Name:
-
QLN-W25PRO
-
Engine:
-
KUBOTA
-
Product name:
-
MINI EXCAVATOR
-
Certification:
-
CE
-
Keywords:
-
Mini Excavator 2ton
-
Total Length(mm):
-
3570
-
Total Width(mm):
-
990
-
Total Height(mm):
-
2250
-
Crawler width(mm):
-
230
-
Wheel spacing(mm):
-
1120
Quick Details
-
Operating Weight:
-
2.5ton
-
Bucket capacity:
-
0.066 m3
-
Engine Brand:
-
Kubota
-
Power:
-
14/2200 rpm
-
Place of Origin:
-
Shandong, China
-
Maximum Digging Height:
-
3880MM
-
Maximum Digging Depth:
-
2550MM
-
Machine Weight:
-
2500 kg
-
Marketing Type:
-
New Product 2024
-
Name:
-
QLN-W25PRO
-
Engine:
-
KUBOTA
-
Product name:
-
MINI EXCAVATOR
-
Certification:
-
CE
-
Keywords:
-
Mini Excavator 2ton
-
Total Length(mm):
-
3570
-
Total Width(mm):
-
990
-
Total Height(mm):
-
2250
-
Crawler width(mm):
-
230
-
Wheel spacing(mm):
-
1120
Product Information
Easy To Use w20
Small and flexible. Suitable for occasions with narrow terrain and limited space.
Easy To Use w25
Small and flexible. Suitable for occasions with narrow terrain and limited space.
Easy To Use w30
Small and flexible. Suitable for occasions with narrow terrain and limited space.
Easy To Use w35
Small and flexible. Suitable for occasions with narrow terrain and limited space.
|
|
Unit
|
W20
|
W25
|
W30
|
W35
|
|
Operating weight
|
kg
|
2000
|
2500
|
3000
|
3500
|
|
Quantity
|
m3
|
0.046
|
0.066
|
0.09
|
0.09
|
|
Bucket width
|
mm
|
450(400)
|
460(410)
|
520(470)
|
520(470)
|
|
Bucket maximum digging force
|
kN
|
15.2
|
18.4
|
26.5
|
26.5
|
|
Robotic arm digging force
|
kN
|
11
|
13.3
|
19.2
|
19.2
|
|
Engine model
|
|
Kubota D902
|
Kubota D1105
|
Yanmar 3TNV88F
|
Yanmar 3TNV88F
|
|
Engine rated power/speed
|
kW/rpm
|
11.8/2300
|
14/2200
|
18.2/2200
|
18.2/2200
|
|
Engine capacity
|
lt
|
0.898
|
1.123
|
1.642
|
1.642
|
|
Pump brand
|
|
Nachi
|
Nachi
|
Nachi
|
Nachi
|
|
Pump type
|
|
Gear pump
|
Plunger pump
|
Plunger pump
|
Plunger pump
|
|
Flow
|
L/min
|
30
|
52
|
70
|
70
|
|
Rotary motor
|
|
EATON
|
LKC
|
EATON
|
EATON
|
|
Travel motor
|
|
Nachi
|
Nachi
|
Nachi
|
Nachi
|
|
Running speed (high/low)
|
km/h
|
2/3.5
|
2.4/4.2
|
3.0/4.2
|
3.0/4.2
|
|
Ground pressure
|
kPa
|
25.5
|
28.4
|
28.4
|
28.4
|
|
Gradeability
|
%
|
58（30）
|
58（30）
|
58（30）
|
58（30）
|
|
Fuel tank capacity
|
L
|
18
|
28
|
40
|
40
|
|
Hydraulic tank capacity
|
L
|
13
|
22.5
|
33
|
33
|
|
Swing speed
|
r/min
|
9.5
|
9.5
|
8.5
|
8.5
|
|
Radius of gyration (minimum value)
|
mm
|
1430
|
1850
|
2035
|
2035
|
|
Rotation angle
|
°
|
65
|
75
|
70
|
70
|
|
|
|
|
|
|
|
|
Maximum digging height
|
mm
|
3540
|
3880
|
4600
|
4600
|
|
Maximum dumping height
|
mm
|
2440
|
2550
|
3175
|
3175
|
|
Maximum digging depth
|
mm
|
2310
|
2320
|
2880
|
2880
|
|
Maximum vertical digging depth
|
mm
|
1910
|
1900
|
2305
|
2305
|
|
Maximum digging radius
|
mm
|
3900
|
4140
|
4965
|
4965
|
|
Maximum digging distance on the ground
|
mm
|
3840
|
4015
|
4845
|
4845
|
|
Dozer blade (length*width)
|
mm
|
1240*268
|
1500*335
|
1550*335
|
1550*335
|
|
Maximum lifting height of dozer blade
|
mm
|
245
|
340
|
360
|
360
|
|
Maximum digging depth of dozer blade
|
mm
|
200
|
270
|
340
|
340
|
|
Radius of gyration
|
mm
|
1430
|
1850
|
2035
|
2035
|
|
Overall dimensions (length x width x height)
|
mm
|
3570*1240*2250
|
3850*1300*2380
|
4485*1550*2440
|
4485*1550*2440
|
|
Total track length
|
mm
|
1860
|
2170
|
2470
|
2470
|
|
Wheel tread
|
mm
|
1230
|
1475
|
1665
|
1665
|
|
Platform ground clearance
|
mm
|
390
|
400
|
420
|
420
|
|
Chassis ground clearance
|
mm
|
145
|
170
|
290
|
290
|
|
Chassis width
|
mm
|
990/1240
|
1300/1500
|
1550
|
1550
|
|
Track width
|
mm
|
230
|
250
|
300
|
300
|
|
Track height
|
mm
|
330
|
350
|
370
|
370
|
Product Detail
W20
Main pump Japan NachiRotary Motor USA EatonWalking Motor Japan Nachiltaly Hydrocontrol main value
W25
Main pump Japan Nachi
Rotary Motor Japan NachiWalking Motor Japan NachiItaly Hydrocontrol main value
W30/35
Korea main value
Main pump Japan Nachi
Rotary Motor Japan Nachi
Walking Motor Japan Nachi
01
Arm Swing Boom
02
Chassis Stretch
03
High Low Speed
04
Hydraulic Pilot Joystick
Attachments
A versatile machine with a wide range of accressries
