Brand Name:: I.C.T

Model Number:: I.C.T-7200

Name:: PCB x-ray Inspection Machine

Product Name:: I.C.T-7200 PCB X-Ray Machine

Certificate:: CE Certificate

Dimension(W*D*H):: 1100*1360*1750 mm

Weight:: 1000KG

Voltage:: 220V/50Hz

Power:: 0.5KW

Application:: BGA, PCB, CSP, LED, Flip Chip, Semiconductor, etc.

Function:: SMT PCB X-Ray

Quick Details

Weight (KG):: 1150

Marketing Type:: New Product 2022

Place of Origin:: Guangdong, China

Brand Name:: I.C.T

Model Number:: I.C.T-7200

Name:: PCB x-ray Inspection Machine

Product Name:: I.C.T-7200 PCB X-Ray Machine

Certificate:: CE Certificate

Dimension(W*D*H):: 1100*1360*1750 mm

Weight:: 1000KG

Voltage:: 220V/50Hz

Power:: 0.5KW

Application:: BGA, PCB, CSP, LED, Flip Chip, Semiconductor, etc.

Function:: SMT PCB X-Ray

High-speed SMT X-Ray Inspection Equipment, PCB X Ray Machine Price, 3D X-ray Inspection (AXI) of PCBs

Product Description

Introduce:

1. Wider Effective Detection Range: Enhances product magnification and detection capabilities.

2. Easy Identification of Product Tilt and Surface Defects: Achieves comprehensive detection without blind spots.

3. Utilizes Top-tier HAMAMATSU × X-ray Source from Japan: Incorporates cutting-edge X-ray technology for precision.

4. Effortless Detection of Semiconductor Package Wire Bending and Breakage: Detects bent or broken semiconductor package wires with ease.

Features

1. CNC program: automatic batch detection of different positions of samples;

2. Array function: automatic batch detection of
samples with fixed positions and the same spacing;

3 . Length and width measurement: measure the length and width of part of the

detection area;

4. Visual navigation interface: precise positioning, X-Y to achieve precise displacement of the joystick;

5.
Simulate color: better observe the inspection image;

6. Bubble measurement: One-key measurement of bubble size, void rate, and tin
climbing height;

7. Automatically ON/OFF X-RAY light tube to detect samples in batches;

8. Equipped with Japanese X-RAY light
tube, the detection accuracy can reach 1um;

9. High-resolution digital X-RAY flat panel;

10. The stage can accommodate a large
number of samples of various sizes;

11. Optional 360° rotation of the stage to detect samples;

12. Allow 60° tilt observation;

13.
Windows navigation, convenient target tracking;

14. Ergonomic design, friendly man-machine interface;

15. High safety, with EU CE Certificate, International Quality Management System ISO, and AERB Certificate for X-ray.

Working Principle

The computer controls the intensity of the XRAY tube emitted by the XRAY, penetrates the Tested object, reaches the Detector, and
the Image Acquisition card converts the signal and sends it back to the computer

Options: Nuclear radiation detector

Multifunctional ray detection, including β, X-ray, γ-ray detection,
Rechargeable design greatly improves battery life, fast test speed,
increased CPM display and automatic range, wider measurement
range, built-in filter function, to avoid other interference

Application:

SMT, BGA, CSP, Flip Chip, LED Detection,Semiconductor, Packaging components, Battery Industry,Electronic components, Automotive, parts, Photo-voltaic,Aluminium Die-casting, Moulding Plastic. Ceramics, other special industries.

Detection case:

Specification:

Item	^Model	^I.C.T-7100	^I.C.T-7900
_{X-Ray Tube}	^Type	^{Closed tube}	^{Enclosed reflective target microfocus X-ray source}
Flat panel detector	^{Max. Inspection area}	^510mm*510mm	^510mm*510mm
Flat panel detector	Flat panel detector	^{Platform rotation angle}	^{60° platform rotation (Optional)}	^{360° platform rotation (Optional)}
Machine Size	^{Dimension (LWH)}	^{110013601750mm}	^{111013502000mm}
