Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YingMan
-
Product Name:
-
German type axle
-
Material:
-
Steel
-
Application:
-
Trailer Truck Used
-
Axle Beam (mm):
-
150*150
-
Certificate:
-
ISO/TS16949
-
Axle Beam:
-
Square 150*150mm/Round 127*127mm
-
Track:
-
1840mm
-
MOQ:
-
1pcs
-
Package:
-
According to customer requirements
Quick Details
-
OE NO.:
-
JDT1001
-
Max Payload:
-
20 ton, 13T-20T
-
Size:
-
560-810mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YingMan
-
Product Name:
-
German type axle
-
Material:
-
Steel
-
Application:
-
Trailer Truck Used
-
Axle Beam (mm):
-
150*150
-
Certificate:
-
ISO/TS16949
-
Axle Beam:
-
Square 150*150mm/Round 127*127mm
-
Track:
-
1840mm
-
MOQ:
-
1pcs
-
Package:
-
According to customer requirements
Product Features
1. One-piece shaft tube, high strength, comfortable appearance.
2. Compared with other axles of the same load, it is light in weight and low in price.
2. Compared with other axles of the same load, it is light in weight and low in price.
3. Using non-asbestos friction plate, more environmentally friendly.
4. Adopting international general specifications, maintenance is convenient, fast and low cost.
4. Adopting international general specifications, maintenance is convenient, fast and low cost.
Description
:Strong one-piece or welded axle head, exceeding the industry standard for hardness and tensile strength.Stable and reliable brake system with non-asbestos brake linings.
1. Products Name: Trailer Axle Parts Standard Size 13T Axle
2. Axle Track: 1840mm
3.Axle Beam: Square 150mm/127mm Round 127mm
4. Product type:American,Germany and Europe type
5.Max.capacity you can choose:12T,13T,14T,15T,16T
6.Stud:10*M20*1.5
7.Material: Steel
8.Products Capacity Available: 13T/14T/16T/18T/20T
1. Products Name: Trailer Axle Parts Standard Size 13T Axle
2. Axle Track: 1840mm
3.Axle Beam: Square 150mm/127mm Round 127mm
4. Product type:American,Germany and Europe type
5.Max.capacity you can choose:12T,13T,14T,15T,16T
6.Stud:10*M20*1.5
7.Material: Steel
8.Products Capacity Available: 13T/14T/16T/18T/20T
Product Paramenters
1. Axle Body Advantage:
Axle tube is made of high-quality alloy steel with a special process, high strength and lightweight, and the two ends of the tube body have good coaxially.
2. Brake Advantage: Brake Shoes Holder six hole boring machine using six completed a one-time processing, high processing, high position precision, asbestos free friction plate, in line with international environmental standards.
3. Quality Assurance:
1). The axle tube assured one year or 150000 km.
2). The brake assy and bearings assured 3 months.
3). The Hubs and Drums assured 6 months.
2. Brake Advantage: Brake Shoes Holder six hole boring machine using six completed a one-time processing, high processing, high position precision, asbestos free friction plate, in line with international environmental standards.
3. Quality Assurance:
1). The axle tube assured one year or 150000 km.
2). The brake assy and bearings assured 3 months.
3). The Hubs and Drums assured 6 months.
|
Model
|
Capacity
(kg) |
Track(mm)
|
Axle Tube
(mm) |
Brake Size
|
PCD
(mm) |
Total Length
(mm) |
Recommended Wheel
|
|||||||
|
YM-F12T
|
12000
|
1840
|
Square150
|
420*180
|
335
|
2165
|
7.5V-20
|
|||||||
|
YM-F14T
|
14000
|
1840
|
Square150
|
420*200
|
335
|
2185
|
7.5V-20
|
|||||||
|
YM-F16T
|
16000
|
1850
|
Square150
|
420*200
|
335
|
2185
|
7.5V-20
|
|||||||
|
YM-F18T
|
18000
|
1850
|
Square150
|
420*220
|
335
|
2185
|
7.5V-20
|
|||||||
|
1. Provide customized services. 2. It can be equipped with ABS brake.
|
|
|
|
|
|
|
|
|||||||
Accessories
It adopts high-quality accessories from major brands at home and abroad, and global standard American axle specifications. It has strong practicability, low price and convenient maintenance.
Axle
The factory produces its own shaft tube with quality assurance and cost advantage. The assembly process strictly abides by international quality standards to create high-quality products.
