Quick Details
-
Application:
-
Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DY
-
Model Number:
-
DY
-
Product Type:
-
High Quality Electric Smart Glass Projection Film
-
Thickness:
-
0.4mm
-
Color:
-
White/Grey
Quick Details
-
Warranty:
-
Lifetime
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Inspection, Free spare parts
-
Project Solution Capability:
-
graphic design, Cross Categories Consolidation
-
Application:
-
Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DY
-
Model Number:
-
DY
-
Product Type:
-
High Quality Electric Smart Glass Projection Film
-
Thickness:
-
0.4mm
-
Color:
-
White/Grey
Dimming film is a new type of electronic light control product. The electrically controlled intelligent dimming film device is a mixture of liquid crystal/polymer material injected between two transparent conductive films. Under the circumstance of no electric field action, the electrically controlled intelligent control film is in an opaque state.
When an alternating current is applied, the liquid crystal molecules are arranged in an orderly manner. At this time, the electromodulating film changes from an opaque (OFF) state to a transparent (ON) state. Through the action of electric field, it can realize the fast conversion from open state to off state, from off state to open state.
1) Under the condition of power off (in the off state), it appears milky white. When energized (in the on state), it is colorless and transparent
2) The light transmittance in the open state shall not be less than 75%, and the light transmittance in the closed state shall not be more than 2%
3) The viewing Angle is not less than 140 degrees
4) Working voltage: 18-75v (AC 50/60 Hz)
5) Response time: OFF → ON is less than 5ms, ON → OFF is less than 50ms
6) Power consumption: 5W/m2
7) Size: standard size is 2600mm*900mm, other sizes can be customized according to customer requirements
8) Operating temperature is -20
o
C
-60
o
C
9) Usage life is more than 50,000 hours
|
Environment Parameter
|
|
Mode
|
Paramter
|
|
|
Optical Parameter
|
Visible Transmittance
|
Power ON
|
>78%
|
|
|
|
|
Power OFF
|
>55%
|
|
|
|
Parallel Transmittance
|
Power ON
|
>66%
|
|
|
|
|
Power OFF
|
<1.5%
|
|
|
|
Haze
|
Power ON
|
<5%
|
|
|
|
|
Power OFF
|
>90%
|
|
|
|
Visula Angle
|
Power OFF
|
>150
0
|
|
|
Electrical Parameter
|
Working Voltage
|
Power ON
|
48V AC
|
|
|
|
Saturation Voltage
|
Power ON
|
<20V
|
|
|
|
Response Time
|
Power OFF - Power ON
|
<200ms
|
|
|
|
|
Power ON - Power OFF
|
<10ms
|
|
|
|
Power
|
Power ON
|
<5W/M
2
|
|
|
Physic Parameter
|
Thickness
|
0.65(MM)
|
|
|
|
|
Max Size
|
<1.5X3.2(M)
|
|
|
|
|
Roll Size
|
1/1.2/1.4/1.5M(W)x20/30/50M(L)
|
|
|
|
|
Adhesive Force
|
25g/mm
|
|
|
|
Environment Parameter
|
Working Temperature
|
-10
0
C-65
0
C
|
|
|
|
|
Storage Temperature
|
-20
0
C-80
0
C
|
|
|
|
|
Life Times
|
POWER ON > 10 Years
|
|
|
|
|
Switch Times
|
>80,000,000
|
|
|
