Horizontal Rapeseed Sunflower Grain Maize Seed Treater Coating Machine

Horizontal Rapeseed Sunflower Grain Maize Seed Treater Coating Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $300

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model:: 60

Material:: SS304 Stainless Steel

Voltage:: 380 v

Power:: 2.2 kw

Capacity:: 500 kg/h

Speed:: 0-25 rpm

Dimension:: 1200*800*1120 mm

Keywords:: seed treatment machine

Quick Details

Place of Origin:: Henan, China

Name:: seed treatment machine manufacturer

Application:: Cereal Grains seeds

Model:: 60

Material:: SS304 Stainless Steel

Voltage:: 380 v

Power:: 2.2 kw

Capacity:: 500 kg/h

Speed:: 0-25 rpm

Dimension:: 1200*800*1120 mm

Keywords:: seed treatment machine

Horizontal Rapeseed Sunflower Grain Maize Seed Treater Coating Machine

Product Description

Introduction:

1. Seed coating is refers to the use of stickers or film forming agent, Use specific seed coating machine, fungicide, pesticides, micronutrient fertilizer, plant growth regulator, stain or filling agent than seed material, wrapped in seed outside, in order to achieve the seeds into spherical or basic keep original shape.

2. It could improve the resistance, disease resistance, speeds up the germination, promote into seedlings, increase production, improve quality of a seed technology.

3. Indicated that can rapidly solidified film, and is not easy to fall off.

Technical Parameters:

Model	50	100	200
Power(kw)	2.2	3	3
Capacity(kg/h)	100	200	300
Speed(r/min)	55	55	55
Cylinder Volume(L)	50	100	150
Outer Size(mm)	550x900x600	600x900x650	1100x700x750
Weight(kg)	65	85	120

Working Principles:

A: Put the mixture to be cut into the hopper, start the machine, and reverse the material in the hopper through the agitator.

B: After the material is evenly mixed, the material can be taken out by reversing.

C: It can be reversed and reversed to greatly improve the mixing effect.

More Details

Detailed Images:

1. It is mainly made of stainless steel, corrosion resistance.

2. Seed dressing applied latest technology institutions.

3. The use of longer mixing drum seed dressing on the seed surface without injury, fast film, you can bag.

4. Seed mixing drum is no residue, easy cleaning machine.

Handling Precautions:

1. Before the operation to ensure that the machine is level and plumb.

2. It shall start operation mixer, then pour into the barrel material.

3. When the machine work must not reach into the mixing barrel.

4. After the material mixing evenly, open the discharge port to discharge flap.

Packaging & Shipping

Delivery time	Within 7-15 working days after receiving your payment;
Payment terms	T/T, L/C, Western Union, Trade Assurance;
Packing	a. Machines are wrapped in plastic film first before packing, which is to avoid moisture on the sea; b. The machines are put in standard export wooden case, lined with metal wire if necessary.
Quality Guarantee Terms	Quality guarantee term is for one year. Malfunctions caused by machine itself and quality will be responsible for our manufacturer. Other malfunctions caused by operation mistakes, man-made problem etc., we won't take responsible.
