Quick Details
-
Model Number:
-
SY-P01A66
-
Thickness:
-
6-200mm, 6-200mm
-
Size:
-
1000*3000mm, 1000*3000mm
-
color:
-
white,black & others
-
type:
-
engineering plastic . HDPE Board
-
water absorption:
-
<0.001%
-
advantages:
-
self-lubricating ,wear -resisting
-
density:
-
0.94-0.98g/cm3
-
working temperature:
-
-269°C--85°C
-
Item:
-
HDPE Board
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Sanyou
-
Model Number:
-
SY-P01A66
-
Thickness:
-
6-200mm, 6-200mm
-
Size:
-
1000*3000mm, 1000*3000mm
-
color:
-
white,black & others
-
type:
-
engineering plastic . HDPE Board
-
water absorption:
-
<0.001%
-
advantages:
-
self-lubricating ,wear -resisting
-
density:
-
0.94-0.98g/cm3
-
working temperature:
-
-269°C--85°C
-
Item:
-
HDPE Board
adhesive backed plastic sheet/chrome plastic sheet/flexible plastic sheet 1mm
1. adhesive backed plastic sheet Advantage
1.Abrasive resistance which always have in thermoelectricity polymer.
2.Best shock resistance even in low temperature.
3.Low frictional factor, and well sliding bearing material.
4.Lubricity( no caking, in adhesion) .
5.Best chemical corrosion resistance and stress craze resistance.
6.Excellent machinery process ability .
7.Lowest water absorption(<0.01%) .
8.Paragon electric insulativity and antistatic behavior .
9. Nice high energy radioactive resistance.
10.Density is lower than other thermoplastics (< 1g/m3).
11.Long using temperature range: -269°C--90°C.
Extruded Plastic Sled
2. adhesive backed plastic sheet Main characteristics:
The main performance comparison
adhesive backed plastic sheet
High abrasion resistance
|
Materials |
UHMWPE |
PTFE |
Nylon 6 |
Steel A |
Polyvinyl fluoride |
Purple steel |
|
Wear Rate |
0.32 |
1.72 |
3.30 |
7.36 |
9.63 |
13.12 |
adhesive backed plastic sheet
Good self-lubricating properties,low friction
|
Materials |
UHMWPE -coal |
Cast stone-coal |
Embroidered plate-coal |
Not embroidered plate-coal |
Concrete coal |
|
Wear Rate |
0.15-0.25 |
0.30-0.45 |
0.45-0.58 |
0.30-0.40 |
0.60-0.70 |
Extruded Plastic Sled
adhesive backed plastic sheet
High impact strength, good toughness
|
Materials |
UHMWPE |
Cast stone |
PAE6 |
POM |
F4 |
A3 |
45# |
|
Impact strength |
100-160 |
1.6-15 |
6-11 |
8.13 |
16 |
300-400 |
700 |
3. adhesive backed plastic sheet Size Available:
|
Dimensions: |
Typical Thickness: |
|
3000mm*1000mm |
5mm-250mm |
|
3000mm*1500mm |
|
|
2000mm*4000mm |
|
|
4000mm*1200mm |
|
|
1200mm*3000mm |
Extruded Plastic Sled
*If required,also available in thickness from 2mm-250mm HDPE Plastic board .
adhesive backed plastic sheet
4. Technical parameter Of adhesive backed plastic sheet
|
Subject |
Unit |
Paraters |
|
Tensile strength |
Mpa |
>30 |
|
Compression strength |
Mpa |
≥41.8 |
|
Bending strength |
Mpa |
≥32 |
|
Impact strength |
KJ/m² |
≥140 |
|
Ball identation strength |
N/mm² |
≥40.8 |
|
Surface resistivity |
Ω |
4.9×10¹³ |
|
Water absorption |
% |
0.0001 |
|
Relative waer rate |
G/cm² |
≤0.09 |
|
Frication coefficent |
% |
<0.09 |
5. adhesive backed plastic sheet Main Products show
1. HDPE/UHMWPE Plate 2. HDPE/UHMWPE Liner
3. HDPE Ground mat 4. HDPE/UHMWPE Fender
5. HDPE/UHMWPE Irregular parts 6. HDPE/UHMWPE Roller
7. HDPE Textured board
adhesive backed plastic sheet
6. Machinery & Packaging & Applictions
1. Chemical Engineering: Corrosion and wear resistantance mechanical parts
2. Thermal power: coal handling, storage of coal, warehousing chute lining
3. Coal processing: sieve plate, filter, U-underground coal chute
4. Concrete: cement raw and finished product silo silo lining
5. Grain: food storage or chute lining
6. Mining: sieve plate, chute linings, wear anti-bonding part
7. Food industry:
star-shaped wheel, transmission timing bottle screw, bearings, guide
rollers, guides, slide blocks, etc.
adhesive backed plastic sheet
More related item:
Factory view:
We are manufacturer of HDPE ,UHMWPE board , also conveyor roller ,plate .
We have passed ISO SGS and CE certification with more than 20 years experience.
Delivery:
1.we are an leading manfuacturer in HDPE and UHMWPE board and roller .
2.Alibaba sccessed 4 years gold supplier with Trade Assureance
3.100% quality inspection before shipping .
4.Best quality with best price for best sevices .
send you detail inquiry in the below ,click "send " now .
