Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE, ROHS
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-MPSG
-
Output Voltage (V):
-
220V
-
Output Frequency:
-
50/60 Hz, 50/60Hz
-
Work Time (h):
-
24 Hours
-
Input Voltage Range:
-
160-275V
-
Battery Rated Voltage:
-
12V/24V
-
Input Frequency:
-
45-65Hz
-
Output Voltage:
-
220V
-
Output Wave:
-
Sine Wave
-
Lithium battery:
-
24V50AH
-
Display:
-
Digital LCD
-
Keyword:
-
portable solar generator
Quick Details
-
Application:
-
Balcony
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE, ROHS
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-MPSG
-
Output Voltage (V):
-
220V
-
Output Frequency:
-
50/60 Hz, 50/60Hz
-
Work Time (h):
-
24 Hours
-
Input Voltage Range:
-
160-275V
-
Battery Rated Voltage:
-
12V/24V
-
Input Frequency:
-
45-65Hz
-
Output Voltage:
-
220V
-
Output Wave:
-
Sine Wave
-
Lithium battery:
-
24V50AH
-
Display:
-
Digital LCD
-
Keyword:
-
portable solar generator
Related Products
Product Description
Key Features:
◆ Excellent performance because of double CPU intelligent control technology;
◆ Built-in LiFePo4 lithium battery;
◆ The mains supply mode/energy-saving mode/battery mode can be set for flexible;
◆ Convenient and practical 5VDC-USB output port and 12VDC output port;
◆ MPPT Controller greatly improving the charging efficiency more than 20%;
◆ Overcharge protechon and overdischarge protection for a longer battery life;
◆ Safe and reliable with intelligent exhaust fan control;
◆ Overall automatic protection and alarms induding AC output overload protection . short arcuit protection . Etc;
Product specification
|
Model
|
|
MPSG-500W
|
MPSG-1000W
|
|
|
Battery Voltage
|
|
12V
|
24V
|
|
|
Inverter
|
RATED POWER
|
800VA/500W
|
1500VA/1000W
|
|
|
|
Input Voltage Range
|
140-275V
|
|
|
|
|
Input Frequency
|
45-65Hz
|
|
|
|
|
Output Voltage
|
220VAC
|
|
|
|
|
Output Frequency
|
50/60Hz
|
|
|
|
|
Output Wave
|
Sine Wave
|
|
|
|
|
Speficifation Of Built-in Lithium Battery
|
12V50AH
|
24V50AH
|
|
|
|
Communication
|
RS232
|
|
|
|
Solar Input
|
Max. PV Power
|
240W
|
480W
|
|
|
|
Max. PV Voltage
|
≤25VDC
|
≤50VDC
|
|
|
|
Range Of Charging Voltage
|
10-25VDC
|
20-50VDC
|
|
|
|
Rated Charge Current
|
20A(MPPT)
|
|
|
|
|
Voltage For Overcharge Protection
|
14.2VDC
|
28.4VDC
|
|
|
|
Voltage For Overcharge Recovery
|
14VDC
|
28VDC
|
|
|
|
Voltage For Floating Charge
|
13.7VDC
|
27.4VDC
|
|
|
DC Output
|
Voltage For High Voltage Protection
|
16VDC
|
32VDC
|
|
|
|
High Voltage Recovery Voltage
|
15.2VDC
|
30.2VDC
|
|
|
|
Low Voltage Recovery Voltage
|
12.6VDC
|
25.2VDC
|
|
|
|
Low Voltage Protecton Voltage
|
11VDC
|
22VDC
|
|
|
|
5VDC USB Output
|
2pcs/MAX 2A
|
|
|
|
|
12VDC Output Ports
|
2pcs/MAX 2A
|
|
|
|
PHYSICAL
|
Heat Dissipation/Cooling
|
Temperature control by intelligent exhaust fan
|
|
|
|
|
Display
|
Digital LCD
|
|
|
|
|
Electricity Charging
|
Yes
|
|
|
|
|
External Size：W*D*H（mm）
|
420*220*270mm
|
430*230*330
mm
|
|
|
|
Package Size：W*D*H（mm）
|
507*295*355mm
|
512*310*405
mm
|
|
|
|
G.W.(Gross Weight)
|
16kg
|
23kg
|
|
