Quick Details
-
Brand Name:
-
Lumiax
-
Model Number:
-
MPPT0850-DCLiR
-
Work Time (h):
-
12 hours
-
Max PV Power:
-
150W
-
Max PV Voltage:
-
45V
-
Certificate:
-
CE
-
Warranty:
-
2 years
-
Rated Voltage:
-
12V
-
Max soloar voltage:
-
45V
-
Max battery voltage:
-
25V
-
MPPT tracking efficiency:
-
>99.9%
-
Max charging conversion:
-
96%
-
Max LED driver efficency:
-
95.5%
-
Battery type:
-
Lithium
-
Load output power:
-
1~60W
-
Self consumption:
-
6mA
-
Protection degree:
-
IP67
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Lighting Controller
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Lumiax
-
Model Number:
-
MPPT0850-DCLiR
-
Work Time (h):
-
12 hours
-
Max PV Power:
-
150W
-
Max PV Voltage:
-
45V
-
Certificate:
-
CE
-
Warranty:
-
2 years
-
Rated Voltage:
-
12V
-
Max soloar voltage:
-
45V
-
Max battery voltage:
-
25V
-
MPPT tracking efficiency:
-
>99.9%
-
Max charging conversion:
-
96%
-
Max LED driver efficency:
-
95.5%
-
Battery type:
-
Lithium
-
Load output power:
-
1~60W
-
Self consumption:
-
6mA
-
Protection degree:
-
IP67
Product Paramenters
|
Type
|
MPPT0850-DCLiR
|
MPPT1050-DCLiR
|
|
|
Max charging current
|
8A
|
10A
|
|
|
Charging voltage target
|
10.0~17.0V(Programmable)
|
|
|
|
Charging voltage recovery
|
9.2~16.8V(Programmable)
|
|
|
|
Low voltage disconnect
|
9.0~15.0V(Programmable)
|
|
|
|
Low voltage reconnect
|
9.6~16.0V (Programmable)
|
|
|
|
Max battery voltage
|
25V
|
|
|
|
0℃ Charging protection
|
Yes, Slow, No(Programmable)
|
|
|
|
Max input power
|
100~120W
|
120~150W
|
|
|
MPPT tracking range
|
(Vb+1.0V)~Voc*0.9 *
|
|
|
|
Day/Night threshold
|
3.0~8.0V (Programmable)
|
|
|
|
Day/Night delay time
|
0~30min(Programmable)
|
|
|
|
Max solar voltage
|
35V
|
45V
|
|
|
Output power
|
1~50W
|
1~60W
|
|
|
Output voltage
|
20~35V
|
20~45V
|
|
|
Output Current
|
0.15~3.0A(Programmable)
|
|
|
|
Voltage of start dimming
|
10.0 ~ Charging voltage target(Programmable)
|
|
|
|
Ambient temperature
|
-35~+60℃
|
|
|
|
Dimming percentage
|
1~20%(Programmable)
|
|
|
|
Induction delay off time
|
10~150s(Programmable)
|
|
|
|
Ambient humidity
|
0 ~ 100%RH
|
0 ~ 100%RH
|
|
|
Max Altitude
|
4000m
|
|
|
100% product quality protection
100% delivery protection on time
100% payment protection
100% payment protection
Our Factory
FAQ
Q1:How long of the warranty or guaranty?
A1:Waterproof controllers 36 months,other controllers 24 months and whole life technical support.
Q2:Can you accept OEM or ODM?
A2: Yes,for batch order, it's absolutely no problem to do OEM and ODM
Q3:What is your delivery time?
A3:It depends on your quantity.Usually 2days for sample and 5-10 days within 500pcs.
Q4:Do you have your own factory?
A4:Yes,we are in controller field for more than 13 years.We have three factories located in Qingdao,China,welcome to visit.
Q5:After-sales service
A5:Professional installation video guidance and technical support.
Q6：What kind of certificate you have?
A6:We have gained CE,ROHS,ISO9001,ISO14001.
A1:Waterproof controllers 36 months,other controllers 24 months and whole life technical support.
Q2:Can you accept OEM or ODM?
A2: Yes,for batch order, it's absolutely no problem to do OEM and ODM
Q3:What is your delivery time?
A3:It depends on your quantity.Usually 2days for sample and 5-10 days within 500pcs.
Q4:Do you have your own factory?
A4:Yes,we are in controller field for more than 13 years.We have three factories located in Qingdao,China,welcome to visit.
Q5:After-sales service
A5:Professional installation video guidance and technical support.
Q6：What kind of certificate you have?
A6:We have gained CE,ROHS,ISO9001,ISO14001.
