Quick Details
-
Supplier Type:
-
PCBA
-
Product name:
-
electric toothbrush pcba service
-
Keywords:
-
electric toothbrush printed circuit board
-
PCBA service:
-
SMD SMT DIP Component Assembly
-
Material:
-
FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum
-
MOQ:
-
1 PCS
-
Application:
-
Home Appliances
-
Service:
-
One-stop Turnkey PCBA Service
-
Testing Service:
-
AOI ICT FCT Visual Inspection
-
PCB Standard:
-
IPC-A-610 D/IPC-III Standard
-
Function:
-
Prototype PCB Assembly
Quick Details
-
Model Number:
-
JH-PCBA-088
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JINHUA
-
Supplier Type:
-
PCBA
-
Product name:
-
electric toothbrush pcba service
-
Keywords:
-
electric toothbrush printed circuit board
-
PCBA service:
-
SMD SMT DIP Component Assembly
-
Material:
-
FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum
-
MOQ:
-
1 PCS
-
Application:
-
Home Appliances
-
Service:
-
One-stop Turnkey PCBA Service
-
Testing Service:
-
AOI ICT FCT Visual Inspection
-
PCB Standard:
-
IPC-A-610 D/IPC-III Standard
-
Function:
-
Prototype PCB Assembly
The smart home connects various devices in the home (see below) through the Internet of Things technology, providing home appliance control, lighting control, telephone remote control, indoor and outdoor remote control, anti-theft alarm, environmental monitoring, HVAC control, infrared forwarding, and programmable timing control various functions and means.
JINHUA Smart Home Appliance PCBA Assembly Services:
*Audio and video equipment PCB assembly
*Lighting system PCB assembly
*Curtain control PCB assembly
*Air conditioning control PCB assembly
*Security system PCB assembly
*Digital cinema system PCB assembly
*AV server PCB assembly
*Shadow cabinet system PCB assembly
*Network appliances PCB assembly
|
Processing Type: SMT Surface Mount THT/DIP Plug-in/Hand Soldering Mixed processing Finished Product Assembly
Type of Test: Visually X-ray Inspection AOI Automatic Optical Inspection Function Test |
Production Equipment: SMT Production Lines: 6 THT Production Lines: 2
YAMAHA High-speed SMT Machine: 6 GKG Solder Paste Printing Machine :4 Jintuo Reflow Soldering Machine: 2 Nitto Wave Soldering Machine: 1
Hand Soldering Lines: 2 Functional Test Lines:2 Conformal Coating Spraying Machine:1 |
Inspection and Testing Equipment: AOI: 2 X-RAY BGA Inspection Machine:1 SINIC-TEK SPI: 1 Smart SMT First Article Inspection Machine:1 Electron Microscope (with measurement function): 2
Other Equipment: Automatic PCB Splitting Machine: 6 Washing Machine: 1 Forming Machine: 2 |
|
Production Capability:
PCB types can be assembled: rigid PCB, flexible PCB, rigid-flex PCB, aluminum PCB; PCB board size can be assembled: maximum 480X510mm; minimum size: 50mm x 50mm; Smallest Component: 01005, 0201,0402 Minimum BGA: 0.3mm pitch for rigid PCB, 0.4mm pitch for PCB; Fine Pitch component: 0.3mm pitch Component Height Limit: 15mm Assembly Accuracy: +/-0.025mm
Lead Time: According to the quantity, from 24h to several weeks SMT Production Capacity: 200-300 million chips/month THT Production Capacity: 13 million chips/month Test Capacity: Depending on customer needs and product conditions |
||
JINHUA SMT Workshop Production Line:
JINHUA DIP Workshop Production Line:
