Quick Details
-
Brand Name:
-
XXW
-
Model Number:
-
KW12
-
Max. Current:
-
16A
-
Operating Temperature:
-
-40-85Degree
-
Protection Level:
-
safe
-
Product Name:
-
Micro Swich
-
Certification:
-
ROHS
-
Application:
-
Auto Electronics
-
Mechanical Life:
-
1000000 Times
-
Temperature Range::
-
-40+85Degree
-
Rated Current,Voltage::
-
5A/250VAC
-
Contact Resistance::
-
≤0.03Ohm
-
Insulation Resistance::
-
≥100MOhm
-
Withstand voltage::
-
AC1500V(50HZ)/min
-
Insertion and extraction force::
-
3-20N
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XXW
-
Model Number:
-
KW12
-
Max. Current:
-
16A
-
Operating Temperature:
-
-40-85Degree
-
Protection Level:
-
safe
-
Product Name:
-
Micro Swich
-
Certification:
-
ROHS
-
Application:
-
Auto Electronics
-
Mechanical Life:
-
1000000 Times
-
Temperature Range::
-
-40+85Degree
-
Rated Current,Voltage::
-
5A/250VAC
-
Contact Resistance::
-
≤0.03Ohm
-
Insulation Resistance::
-
≥100MOhm
-
Withstand voltage::
-
AC1500V(50HZ)/min
-
Insertion and extraction force::
-
3-20N
|
Operation Speed
|
0.05mm-1m/s (Plunger type)
|
|
Operating Frequency
|
Electrical: 20 operations/min
|
|
Contact Resistance
|
15mΩ max. (initial avalue)
|
|
Insulation Resistance
|
100mΩ min. (at 500VDC)
|
|
Dielectric Strength |
1000VAC, 50/60 Hz for 1 minute between terminals of the same polarity
|
|
|
1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts
|
|
|
1500VAC, 50/60 Hz for 1 minute between each terminal and ground
|
|
Vibration
|
(＊10 to 20 Hz): 1.5Vibration amplitude action duration: 10 to 55 Hz
|
|
Shock
|
Mechanical durable: 1,000m/Sec² (about 100G'S)Malfunction: 100m/Sec² (about 30G'S)
|
|
Ambient temperature
|
Using: -20~+80℃ (With no icing)
|
|
Humidity
|
General purpose type: 85% RH max., Sealed type: 95% RH max.
|
|
Electrical Life
|
500,000 operations above
|
|
Weight
|
About 22 to 58g
|
Q1: Are you a factory or trading company?
We are factory and produce all the products by our self. Welcome to our company for factory inspection.
Q2: What products does your factory mainly manufacture?
Our factory mainly produces rocker switch, push button switch, micro switch, tact switch, toggle switch, coding switch, self
locking&unlocked switch, ac&dc socket and etc.
Q3: How to guarantee our products?
we solemnly promise If there are any quality problems we will be 100% responsible for rectification.
Q4: Is it possible to customize the product according to our requirements?
You can provide us with your specific product requirements, we will manufacture the products you need individually for you.
Q5: Can you provide samples ? Are the samples free?
Yes, we can provide samples. Normally, we provide free samples for test or quality checking.
Q6: About the sample what is the cost of transportation?
The freight depends on weight, packing size and your country or province region, etc.
You can confirm goods by photo and video to save this money, If you become our old customer.
Q7: How to order?
Please contact us.
