Quick Details
-
Brand Name:
-
KangJia
-
Power:
-
7.5 kw
-
Weight:
-
600 KG
-
Cutting speed:
-
max. 1400mm /s
-
Cutting thickness:
-
≤50mm
-
Effective cutting area:
-
1500*1600(L*W
-
Cutting accuracy:
-
±0.1mm
-
Cutting tool:
-
Oscillating knfie
-
Location mode:
-
Infrared laser
-
Material fixation method:
-
Vacuum adsorption
-
Transmission interface:
-
Network transmission
-
Certification:
-
CE ISO9001
-
Guide rails:
-
PMI
Quick Details
-
Voltage:
-
110V/220V/380V±10%,50HZ 60HZ
-
Marketing Type:
-
Hot Product 2022
-
Place of Origin:
-
CHO
-
Brand Name:
-
KangJia
-
Power:
-
7.5 kw
-
Weight:
-
600 KG
-
Cutting speed:
-
max. 1400mm /s
-
Cutting thickness:
-
≤50mm
-
Effective cutting area:
-
1500*1600(L*W
-
Cutting accuracy:
-
±0.1mm
-
Cutting tool:
-
Oscillating knfie
-
Location mode:
-
Infrared laser
-
Material fixation method:
-
Vacuum adsorption
-
Transmission interface:
-
Network transmission
-
Certification:
-
CE ISO9001
-
Guide rails:
-
PMI
Product Paramenters
|
Model
|
CTA-SL1615
|
CTA-SL1625
|
CTA-DT1625
|
|
PowerEffective cutting area
|
1500*1600(L*W)
|
2500*1600(L*W)
|
2500*1600(L*W)
|
|
Operating mode
|
automatic
|
automatic
|
Semi-automatic
|
|
Voltage
|
110V/220V/380V±10%, 50HZ 60HZ
|
110V/220V/380V±10%, 50HZ 60HZ
|
110V/220V/380V±10%, 50HZ 60HZ
|
|
Cutting speed
|
max 1200mm/s (standard version)
|
max 1200mm/s (standard version)
|
max 1200mm/s (standard version)
|
|
Cutting thickness
|
≤50mm
|
≤50mm
|
≤50mm
|
|
Effective cutting area
|
7.5/9KW
|
9KW
|
9KW
|
|
Cutting accuracy
|
±0.1mm
|
±0.1mm
|
±0.1mm
|
|
Cutting Materials
|
Flexible Materials
|
Flexible Materials
|
Flexible Materials
|
|
Material fixation method
|
vacuum adsorption
|
vacuum adsorption
|
vacuum adsorption
|
|
Compatible software
|
KANGJIA software
|
KANGJIA software
|
KANGJIA software
|
|
Control system
|
LED touch screen
|
LED touch screen
|
LED touch screen
|
|
Transmission interface
|
USB /inernet port
|
USB /inernet port
|
USB /inernet port
|
|
Drive motor
|
Delta/Innovative (standard version)
|
Delta/Innovative (standard version)
|
Delta /Innovative(standard version)
|
|
Rail
|
PMI
|
PMI
|
PMI
|
|
Safety device
|
emergency stop button, infrared beam, anti-collision
|
emergency stop button, infrared beam, anti-collision
|
emergency stop button, infrared beam, anti-collision
|
|
Architecture
|
integrated framework
|
integrated framework
|
integrated framework
|
Products Description
Quality：
Integrated welding frame body,the preferred parts work stable,long service life.
Service:
Lifetime after-sales, 24-hour standby service free update software,version and other
regular visits.
Secure：
Infrared induction + mechanical collision avoidance system is safer
and more assured.
Feature:
Eight kinds of cutter head interchange, meet a variety of materials cutting，punching.indentation,etc., One machine multi-purpose support multi-cutter head equipment
customization.
Precision：
Higher cutting accuracy.
The error is within 0.lmm.
Environmental protection:
Cold cutting dust-free, smoke-free,natural environmental protection does not destroy the material
Brain power:
Automatic cutting equipment, automatic plate holding software.
Save materials and eliminate waste.
Details Images
Certifications
Application
Product packaging
Why Choose Us
FAQ
Q: 1. How can I choose a suitable cutting machine?A: Please provide us some info, then we can recommend you the suitable machine:
1)What materials are going to cut?
2)What's the largest size of original materials?
3)What's the thickness of materials?
Q: 2. Can you design a machine for me depending on my requirements?
A: Of course, we will discuss details with you and give you our professional suggestion for the machine ensure the machine could match all your requests with best cost performance.
Q: 3. What should I do if the machine has any problem in future?
A: We supply online technical support and door to door service. Anything confuse you, just contact us.
Q: 4. What's the warranty policy?
A:Standard warranty is 12 months upon delivery. Main parts are free of charge(except consumable parts) when problems happened because of quality problem during this period. Problems caused by wrong operate will also well-solved.
Q:5.What is the Price and payment terms?
A:EXW,CIF,FOB we all can accept payment:TT/Paypay/LC/Western Union.etc
Q: 6.What's the package?
A: Film packaging+wooden case. Fumigation-free plywood case is also available
