Quick Details
-
Voltage:
-
380V 50Hz
-
Power:
-
8.1KW
-
Dimension(L*W*H):
-
697*937*1480mm
-
Weight:
-
151 KG
-
Machinery Type:
-
solvent distillation machinery
-
Minimum Order Quantity:
-
1 unit
-
Automatic Grade:
-
Semi-Automatic
-
Volume:
-
90 Liters
-
Certificates:
-
Explosion-proof,CE,ISO9001,ISO14001
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Core Components:
-
Condenser and Heater
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Calstar
-
Voltage:
-
380V 50Hz
-
Power:
-
8.1KW
-
Dimension(L*W*H):
-
697*937*1480mm
-
Weight:
-
151 KG
-
Machinery Type:
-
solvent distillation machinery
-
Minimum Order Quantity:
-
1 unit
-
Automatic Grade:
-
Semi-Automatic
-
Volume:
-
90 Liters
-
Certificates:
-
Explosion-proof,CE,ISO9001,ISO14001
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Video technical support
Product description
Product Photos
Detailed images
Technical data
|
Imput volume
|
90 L
|
Length
|
697 mm
|
|
Capacity of Tank
|
120 L
|
Width
|
937 mm
|
|
Capacity of heat transfer oil
|
36 L
|
Height
|
1480 mm
|
|
Power of heater
|
8.0 KW
|
Weight
|
151 KG
|
|
Max power
|
8.1 KW
|
Temp. of operation
|
50~190 °C
|
|
Max current
|
12.3 A
|
Ideal room temp.
|
5~30 °C
|
|
Power supply
|
380V AC/50 HZ
|
Noise
|
around 50 db
|
|
Recovery rate
|
95%
|
Voltage of control unit
|
24V DC
|
|
Heating method
|
Indirect heating by heat transfer oil
|
Cycle time
|
around 4 Hours
|
|
Flow of cooling water
|
>120 L/H
|
Cooling system
|
Water-cooled
|
|
Max pressure of Condenser
|
30 Bar
|
Temp. of cooling water
|
25°C suggested
|
|
Solvent imput
|
Manual ( automatic imput unit is available)
|
Operational Temp. of Condenser
|
-160°C~+200°C
|
|
Vacuum unit
|
None(option addable)
|
Material of case
|
Carbon steel with paint, or SUS304
|
|
Material of tank
|
SUS304, double layers
|
|
|
NOTE: Values listed above are under ideal conditions in laboratory, just for your reference. The realistic data will be a little deviation due to the difference of waste content, boiling point of solvent, room temperature, viscosity etc.
Recoverable solvents list
Unrecoverable solvents list
Main Features
Flow chart
Schematic Diagram
Packing and Delivery
Related products
Our Service
1. Quick response within 3 hours.
2. Products with international certificate.
3. Products 100% QC checked before shipping.
4. Three-year warranty for completed machine except Heat transfer oil, Gaskets and switches.
5. Customization and Buyer label offered are available.
6. providing professional solution of solvent recovery.
7. providing solvent sample analysis and optimizing solvent formula for free.
8. Wholesale and retail.
9. Pre-sales inquiry and consulting.
10. On site installation and operation training after sales while Volume of machine is 200L equal or above. On the contrary, video of installation and operation training provided.
Our Company
Certifications
Exhibition
Our clients
FAQ
1. How long does your warranty last?
It lasts three years for completed machine except Heat transfer oil, Gaskets and switches.
2. Can you do OEM?
Yes, OEM and buyer label offered are available.
3. What certificates are your products in compliance with?
Our products are in compliance with Chinese Explosion-proof standard(CNEX), European standard(ATEX) and CE. And our company has passed ISO9001 and ISO14001.
4. What kinds of payment do you accept?
L/C and T/T are both acceptable.
5. What is your lead time?
15 days after payment if equipment in stock, or 30 days after payment if equipment customized.
6. What is the package? Is it reliable?
We use seaworthy standard wooden box. It’s fairly reliable.
7. Are free spare parts available after sales?
Yes, free spare parts are available within warranty. And fare of spare parts will be charged after warranty expired.
8. What would you do if breakdown happened with your machine?
We will send our professional engineer to solve this breakdown on site if it is severe and impacted the main function of machine. In this situation, we may have to negotiate some charges. On the contrary, if the breakdown is unimportant, and won’t impact main function of machine, video call will be enough.
