Quick Details
-
Brand Name:
-
OEM
-
Use:
-
WDM Network
-
Warranty Time:
-
5-lifetime
-
Product name:
-
CWDM/DWDM Mux/Demux
-
Operating wavelength:
-
1270~1610nm
-
Center Wavelength Accuracy:
-
±0.5nm
-
Certification:
-
FCC, ce
Quick Details
-
Type:
-
Fiber optic terminal box
-
Model Number:
-
Mux/Demux
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Use:
-
WDM Network
-
Warranty Time:
-
5-lifetime
-
Product name:
-
CWDM/DWDM Mux/Demux
-
Operating wavelength:
-
1270~1610nm
-
Center Wavelength Accuracy:
-
±0.5nm
-
Certification:
-
FCC, ce
OEM/ODM Manufacturer Passive Multiplexer CWDM Mux/Demux Single Fiber LC 8CH
Application :
a WDM Network
b Telecommunication
c Metro Network
d Access System
|
Parameter |
CWDM Mux or D emux 4ch, 8ch,16ch |
||
|
Operating Wavelength |
1 27 0~1610nm |
||
|
Channel Number |
4 |
8 |
16 |
|
Center Wavelength Accuracy |
±0.5nm |
||
|
Bandwidth @ -0.5dB |
≥ 1 4 |
||
|
Insertion Loss(excluding connector loss) |
≤1.8dB |
≤2.8dB |
≤3.8dB |
|
Directivity |
≥ 50dB |
||
|
Optical Input Return Loss |
≥ 45dB |
||
|
Adjacent Channel Isolation |
≥ 30dB |
||
|
Non-Adjacent Channel Isolation |
≥ 40dB |
||
|
Polarization Dependent Loss |
≤0.15 dB |
||
|
Temperature Dependent Loss |
≤0.45 dB |
||
|
Optical Power Handling |
≥ 300mW |
||
|
Operating Temperature |
0 to +65 ℃ |
||
|
Storage Temperature |
-40 to +85 ℃ |
||
|
Fiber Type/length |
SMF-28e fiber, φ 0.9 mm pigtail or 3mm cable , 1+/-0.1m |
||
