Quick Details
-
Brand Name:
-
JINGYAN
-
Model Number:
-
JY-60A
-
Inner box size:
-
600* 450 *400 mm
-
Salt spray test:
-
NSS, ACSS
-
Temperature Test chamber:
-
NSS.ACSS 35℃±1℃/CASS 50℃±1℃
-
Temperature Air cylinder:
-
NSS.ACSS 47℃±1℃/CASS 63℃±1℃
-
PH:
-
6.5~7.2 / 3.0~3.2
-
Spray quantity:
-
1.0~2.0ml/80cm2/h
-
Meet the standards:
-
ASTM B117
-
Power supply:
-
AC220V 50HZ
-
Application:
-
Salt Spray Test Chamber
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JINGYAN
-
Model Number:
-
JY-60A
-
Inner box size:
-
600* 450 *400 mm
-
Salt spray test:
-
NSS, ACSS
-
Temperature Test chamber:
-
NSS.ACSS 35℃±1℃/CASS 50℃±1℃
-
Temperature Air cylinder:
-
NSS.ACSS 47℃±1℃/CASS 63℃±1℃
-
PH:
-
6.5~7.2 / 3.0~3.2
-
Spray quantity:
-
1.0~2.0ml/80cm2/h
-
Meet the standards:
-
ASTM B117
-
Power supply:
-
AC220V 50HZ
-
Application:
-
Salt Spray Test Chamber
A pplication: The salt spray test machine is used for the surface treatment of various materials, including coatings, electroplating, organic and inorganic coatings, anodizing, anti-rust oil and other anti-corrosion treatments to test its corrosion resistance, thus establishing the quality of the product
|
Model |
JY-60A |
JY-90A |
JY-120A |
JY-200A |
|
Design S tandard s |
GB/T 10587-2006 , GB/T 10125-1997 , JISD0201,H8502,H8610,K5400,Z2371 |
|||
|
Test chamber capacity ( L ) |
108L |
270L |
600L |
1440L |
|
Temperature |
Test chamber |
NSS.ACSS 35°C±1°C/CASS 50°C±1°C |
||
|
A ir cylinder |
NSS.ACSS 47°C±1°C/CASS 63°C±1°C |
|||
|
Test chamber size LxWxD(cm) |
60*45*40
|
90*60*50
|
120*100*50
|
200*120*60
|
|
Max volum of t est liquid ( L ) |
15 |
25 |
40 |
40 |
|
Volume LxWxD ( cm ) |
107*60*118 |
141*88*128 |
190*130*140 |
270*150*150 |
|
P ower |
AC220V,10A |
AC220V,15A |
AC220V,30A |
AC220V,30A |
|
Spray quantity |
1.0~2.0ml/80cm2/h |
|||
|
PH |
6.5~7.2 3.0~3.2 |
|||
