Single Stage Insulation Oil Vacuum System Purifying Oil Filtration/transformer Oil Treatment Machine

Single Stage Insulation Oil Vacuum System Purifying Oil Filtration/transformer Oil Treatment Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $5500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Voltage:: 220~415 V

Power:: 12-40kw

Dimension(L*W*H):: 1.3 m X 0.98 m X 1.45m

Weight:: 900 kg

Color:: Blue,grey, green, yellow

Material:: Carbon steel

Application:: Waste Lubricants

End product:: Clean Clear Oil

After Warranty Service:: Video technical support

Quick Details

Flow:: 20-200 L/MIN

Place of Origin:: Chongqing, China

Brand Name:: KAIQIAN

Voltage:: 220~415 V

Power:: 12-40kw

Dimension(L*W*H):: 1.3 m X 0.98 m X 1.45m

Weight:: 900 kg

Color:: Blue,grey, green, yellow

Material:: Carbon steel

Application:: Waste Lubricants

End product:: Clean Clear Oil

After Warranty Service:: Video technical support

Product Overview

High output used oil recycling equipment transformer oil dehydration machine continuous oil refining plant / transformer oil dehydr Wechat/whatsapp : +86 130 3632 7228

USAGE:

1 .It is widely used in oil purification and vacuum drying during installation and maintenance of transformer equipment. Not only suitable for 110 KV-330 KV transformer insulation oil dehydration plant, but also suitable for deep treatment of high-grade new oil and imported oil. Compared with single-stage vacuum oil purifier, it equipped with roots pump system, high vacuum separation system. But also with function of dehydration, de-acetylene, de-acidification, remove free carbon, etc.,it is suitable for insulation oil purification. Transformer oil recycling machine.

2.Besides it also can be used as an independent vacuum drying unit and oil filling machine for transformer. vacuum drying unit by connecting the transformer with vacuum drying interface.

FEATURES AT A GLANCE

Main functions:
1. Vacuum dehydration and degassing;
2. High filter accuracy, filter 99.8% impurities bigger than 1 microns;
3. Reduce acidity of transformer oil;
4. Change dark color of transformer oil to clear;
5. Improve oil dielectric strength (BDV) value upto 75kV;
6. Vacuum oil filling;
7. Vacuum pumping for transformer;
8. Hot oil circulation for transformer;

Right elevation

Left elevation

Front elevation

Product Paramenters

Parameter	Unit	TY-R20	TY-R30	TY-R50	TY-R80	TY-R100	TY-R150
Flow Rate	L/min	20	30	50	80	100	150
Working Vacuum	Mpa	－0.08～－0.096
Working Pressure	Mpa	≤0.5
Working Temp.	℃	≤10～80 Adjusted free
Power	V	380 V/480 V/50 Hz-60 Hz ,customize as per client requests
Electrical Heating	KW	24	30	36	42	54	66
Total Power	KW	26	33	39	45	57	72
