Quick Details
-
Warranty:
-
12 months
-
Place of Origin:
-
China
-
Brand Name:
-
VLAIS, VLAIS
-
Model Number:
-
KDE-30T
-
Speed:
-
1500/1800r/min
-
Weight:
-
850 kg
-
Prime power output(kva/kw):
-
36/45
-
Control panel:
-
Deepsea /Smartgen 6110
-
Fuel Tank:
-
68 L
-
Cooling system:
-
Water-cooled Radiator
-
Fuel Consumption at full load(L/h):
-
7.8
-
Engine type:
-
four-cylinder, vertical, 4-stroke diesel engine
-
Dimension(L*W*H)m:
-
2.1*1.02*1.15
-
Certification:
-
CE;ISO9001
Quick Details
-
Rated Voltage:
-
110/220V/380V
-
Rated Current:
-
36.1A
-
Frequency:
-
50/60HZ
-
Warranty:
-
12 months
-
Place of Origin:
-
China
-
Brand Name:
-
VLAIS, VLAIS
-
Model Number:
-
KDE-30T
-
Speed:
-
1500/1800r/min
-
Weight:
-
850 kg
-
Prime power output(kva/kw):
-
36/45
-
Control panel:
-
Deepsea /Smartgen 6110
-
Fuel Tank:
-
68 L
-
Cooling system:
-
Water-cooled Radiator
-
Fuel Consumption at full load(L/h):
-
7.8
-
Engine type:
-
four-cylinder, vertical, 4-stroke diesel engine
-
Dimension(L*W*H)m:
-
2.1*1.02*1.15
-
Certification:
-
CE;ISO9001
Product Description
| Rated output(KW) | 30 |
| Max.output(KVA) | 37.5 |
| Frequency(HZ) | 50HZ |
| Rated voltage(V) | 220/380V(3phase) |
| Rated current(A) | 54.1 |
| Engine Model | 4100D |
| Cylinder number | 4 |
| Fuel tank capacity | 68L |
| bore*stroke(mm) | 100*115 |
| Fuel consumption(g/kw.h)at full load | 230 |
| Compression ratio | 19:01 |
| Starting system | Electric starter |
| Rated Rotation Speed(rpm) | 1500 |
| Power factor Cos% | 0.8 |
| Insulation grade | H |
| Excitation mode | self-excitation and cinstant voltage(AVR) |
| Diamension(L*W*H) | 2000*900*1400 |
| net weight(KG) | 1180Kg |
