Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DMKE
-
Model Number:
-
DMKE-DC WORM GEAR MOTOR
-
Torque:
-
1-12.5N.M
-
Direction of Rotation:
-
CW/CCW
-
Rated Voltage:
-
12-42V
-
Rated Power:
-
5-120W
-
Rated Speed:
-
30-300rpm/min
-
Life time:
-
2500-3000H
-
Working temperature:
-
-10--80℃
-
protection rank:
-
IP54
-
Environment temperature:
-
-10--40℃
-
Motor type:
-
dc worm gear motor
-
Certification:
-
ce,VDE,RoHS
Quick Details
-
Speed(RPM):
-
30-300rpm/min
-
Continuous Current(A):
-
0.8A-1.5A
-
Efficiency:
-
IE 2
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DMKE
-
Model Number:
-
DMKE-DC WORM GEAR MOTOR
-
Torque:
-
1-12.5N.M
-
Direction of Rotation:
-
CW/CCW
-
Rated Voltage:
-
12-42V
-
Rated Power:
-
5-120W
-
Rated Speed:
-
30-300rpm/min
-
Life time:
-
2500-3000H
-
Working temperature:
-
-10--80℃
-
protection rank:
-
IP54
-
Environment temperature:
-
-10--40℃
-
Motor type:
-
dc worm gear motor
-
Certification:
-
ce,VDE,RoHS
|
Product Performance
|
DMKE-49R/L
|
DMKE-59R/L
|
DMKE-63R/L
|
DMKE-76R/L
|
|
Rated Voltage
|
12-42V
|
12-42V
|
12-42V
|
12-42V
|
|
Rated Current
|
0.8A-1.5A
|
0.8A-1.5A
|
1.0A-1.5A
|
1.2A-1.5A
|
|
Power
|
10-25W
|
20-60W
|
30-90W
|
30-90W
|
|
No load spped
|
15-180RPM
|
15-200RPM
|
30-180RPM
|
30-200RPM
|
|
Load speed
|
10-150RPM
|
10-180RPM
|
25-150RPM
|
25-180RPM
|
|
Gear Ratio
|
1:28-1:70
|
1:28-1:72
|
1:20-1:70
|
1:20-1:70
|
For More Details Of Product Specifications,
Please
CLICK HERE
to contact me
.
Motor length, shaft, voltage, power, rated speed etc are customizable.
Electronic Rotor
Pure copper coil configuration, reducing resistance and high conductivity to ensure motor efficiency, stable and safe operation
Gear
Plastic gear and copper can be selected.
Magnet
Thickened magnets, strengthen the magnetic filed, high torque and strong anti-interference
Gearbox
All made of high quality metal, it has good impact resistance, durability, long lifeand reducing noise.
DMKE motor was founded in China, Guangzhou city，Panyu district, in 2009. After 12 years’ creativity and development, we became one of the leading high-tech companies in China in dc motor industry.
We specialize in high precision micro dc gear motors, brushless motors, brushless controllers, dc servo motors, dc servo
controllers etc. And we produce brushless dc motor and controller with wide power range from 5 watt to 20 kilowatt; also dc servo motor power range from 50 watt to 10 kilowatt. They are widely used in automatic guided vehicle , robots, lifting
equipment,cleaning machine, medical equipment, packing machinery, and many other industrial automatic equipments.
With a plant area of 4000 square meters, we have built our own supply chain with high quality control standard and passed ISO9001 certificate of quality system.
With more than 10 engineers for brushless dc motor and controllers’ research and development, we own strong independent design and development capability. Custom-made motors and controllers are widely accepted by us. At the same time, we have engineers who can speak fluent English. That makes we can supply intime after-sales support and guidance smoothly for our customers.
Our motors are exported worldwide, and over 80% motors are exported to Europe, the United States, Saudi Arabia, Australia, Korea etc. We are looking forward to establishing long-term business relationship together with you for mutual business success.
We specialize in high precision micro dc gear motors, brushless motors, brushless controllers, dc servo motors, dc servo
controllers etc. And we produce brushless dc motor and controller with wide power range from 5 watt to 20 kilowatt; also dc servo motor power range from 50 watt to 10 kilowatt. They are widely used in automatic guided vehicle , robots, lifting
equipment,cleaning machine, medical equipment, packing machinery, and many other industrial automatic equipments.
With a plant area of 4000 square meters, we have built our own supply chain with high quality control standard and passed ISO9001 certificate of quality system.
With more than 10 engineers for brushless dc motor and controllers’ research and development, we own strong independent design and development capability. Custom-made motors and controllers are widely accepted by us. At the same time, we have engineers who can speak fluent English. That makes we can supply intime after-sales support and guidance smoothly for our customers.
Our motors are exported worldwide, and over 80% motors are exported to Europe, the United States, Saudi Arabia, Australia, Korea etc. We are looking forward to establishing long-term business relationship together with you for mutual business success.
Q1: What kind motors you can provide?
A1: For now, we mainly provide permanent magnet brushless dc motor, dc gear motor, micro dc motor, planetary gear motor, dc servo motor, brush dc motors, with diameter range from 16 to 220mm,and power range from 5W to 20KW.
Q2: Is there a MOQ for your motors?
A2: No. we can accept 1 pcs for sample making for your testing,and the price for sample making will have 10% to 30% difference than bulk price based on different style.
Q3: Could you send me a price list?
A3: For all of our motors, they are customized based on different requirements like power, voltage, gear ratio, rated torque and shaft diameter etc. The price also varies according to different order qty. So it’s difficult for us to provide a price list. If
you can share your detailed specification and order qty, we’ll see what offer we can provide.
Q4: Are you motors reversible?
A4: Yes, nearly all dc and ac motor are reversible. We have technical people who can teach how to get the function by different wire connection.
Q5: Is it possible for you to develop new motors if we provide the tooling cost?
A5: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we’ll make our evaluation to see if we can arrange or not.
Q6:How about your delivery time?
A6: For micro brush dc gear motor, the sample delivery time is 2-5 days, bulk delivery time is about 15-20 days, depends on the order qty. For brushless dc motor, the sample deliver time is about 10-15 days; bulk time is 15-20 days.Please take the sales confirmation for final reference.
Q7:What's your warranty terms?
A6: One year
A1: For now, we mainly provide permanent magnet brushless dc motor, dc gear motor, micro dc motor, planetary gear motor, dc servo motor, brush dc motors, with diameter range from 16 to 220mm,and power range from 5W to 20KW.
Q2: Is there a MOQ for your motors?
A2: No. we can accept 1 pcs for sample making for your testing,and the price for sample making will have 10% to 30% difference than bulk price based on different style.
Q3: Could you send me a price list?
A3: For all of our motors, they are customized based on different requirements like power, voltage, gear ratio, rated torque and shaft diameter etc. The price also varies according to different order qty. So it’s difficult for us to provide a price list. If
you can share your detailed specification and order qty, we’ll see what offer we can provide.
Q4: Are you motors reversible?
A4: Yes, nearly all dc and ac motor are reversible. We have technical people who can teach how to get the function by different wire connection.
Q5: Is it possible for you to develop new motors if we provide the tooling cost?
A5: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we’ll make our evaluation to see if we can arrange or not.
Q6:How about your delivery time?
A6: For micro brush dc gear motor, the sample delivery time is 2-5 days, bulk delivery time is about 15-20 days, depends on the order qty. For brushless dc motor, the sample deliver time is about 10-15 days; bulk time is 15-20 days.Please take the sales confirmation for final reference.
Q7:What's your warranty terms?
A6: One year
