Quick Details
-
Color:
-
Full color
-
Panel Size:
-
1000*500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
C-Trans P2.8x5.6 1000x500mm
-
Pixel Pitch:
-
2.8x5.6mm, H:2.8 mm,V:5.6mm
-
Permeability(%):
-
≥48%
-
Pixel color:
-
1R1G1B
-
Working voltage:
-
AC200V-240V
-
Material:
-
Cast aluminum + profile
-
Refresh Rate:
-
356*88Dots
-
Cabinet Weight(kg/Cabinet):
-
7kg/ Cabinet
-
view angel:
-
H/V:140°/140
-
White balance:
-
≥2000 CD/㎡
-
Refresh frequency:
-
≥1920Hz
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
Chipshow
-
Color:
-
Full color
-
Panel Size:
-
1000*500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
C-Trans P2.8x5.6 1000x500mm
-
Pixel Pitch:
-
2.8x5.6mm, H:2.8 mm,V:5.6mm
-
Permeability(%):
-
≥48%
-
Pixel color:
-
1R1G1B
-
Working voltage:
-
AC200V-240V
-
Material:
-
Cast aluminum + profile
-
Refresh Rate:
-
356*88Dots
-
Cabinet Weight(kg/Cabinet):
-
7kg/ Cabinet
-
view angel:
-
H/V:140°/140
-
White balance:
-
≥2000 CD/㎡
-
Refresh frequency:
-
≥1920Hz
FEATURES
1. Lightweight and transparent: weight is only 16kg/㎡, single box weighs 7Kg, box thickness is 47.5mm (including power box 97mm);
Easy to install and maintain, no need for supporting structure reinforcement cost, high benefit;
2. High transparency: ≥48% transparency, it becomes a lifelike video wall without affecting the outdoor vision;
3. All-weather: resistant to various working conditions such as low temperature, high temperature, humidity, etc;
4. Ventilation: The module is grid-shaped, and the wind can directly pass through the module, which greatly saves the cost of the steel structure;
5. Front and rear maintenance of the module: It can be installed and maintained from the front/back to improve the adaptability of the product to the on-site installation conditions;
6. Large box size: 1 meters long x 0.5 meters high, effectively reducing the workload of installation.
