Quick Details
-
Power:
-
0-80KW
-
Dimension(L*W*H):
-
Based
-
Weight:
-
200 KG
-
Machinery Capacity:
-
200 Set/Month
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
1000L Wine /beer jacketed fermentation tank 2016
-
Material:
-
SUS304/304L/316/316L
-
Surface treatment:
-
Mirror or Polished
-
Certification:
-
ISO ,CE
-
Type:
-
Single wall / two layered /three layred
-
With Agiator:
-
Yes /No
-
Price available:
-
FOB & CIF &CFR
-
Heating method:
-
Electric Heating /Steam Heating
-
Capicity:
-
500L-2000L
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
KQ
-
Voltage:
-
Request
-
Power:
-
0-80KW
-
Dimension(L*W*H):
-
Based
-
Weight:
-
200 KG
-
Machinery Capacity:
-
200 Set/Month
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
1000L Wine /beer jacketed fermentation tank 2016
-
Material:
-
SUS304/304L/316/316L
-
Surface treatment:
-
Mirror or Polished
-
Certification:
-
ISO ,CE
-
Type:
-
Single wall / two layered /three layred
-
With Agiator:
-
Yes /No
-
Price available:
-
FOB & CIF &CFR
-
Heating method:
-
Electric Heating /Steam Heating
-
Capicity:
-
500L-2000L
1000L Wine /beer jacketed fermentation tank 2016
( for our better quotation ,show us your drawing if necessary ,tks ! )
1000L Wine /beer jacketed fermentation tank 2016
1.
|
material |
SS304/304L/316/316L |
|
fermenter structure |
dish top cover |
|
cylinder body |
|
|
60°-90° cone botton |
|
|
dimple plate jacket for cooling |
|
|
PU Foam insulation |
|
|
polishing |
mirror polished for interior surface 3A finished , RA≤0.22um |
|
satin polished for exterior surface , 2B finished |
|
|
conical fermenter manway |
550mm*430mm elliptical manway , can be opened inwards & outwards |
|
connect style |
tri-clamp Nozzles on the tank |
|
male- thread Nozzles for jacket |
|
|
fermenter standard fitting |
360°ratated CIP Spraying Ball*1 |
|
sample valve *1 |
|
|
temperature probe in thermowell *1 |
|
|
racking arm on cone *1 |
|
|
botton outlet *1 |
|
|
butterfly valve *2 |
|
|
optional fitting |
carbonate stone |
|
pressure relief valve |
|
|
hops inlet on top |
