- Product Details
- {{item.text}}
Quick Details
-
Drilling Diameter:
-
34mm
-
Drilling Depth:
-
Max.15m
-
Product name:
-
portable core drilling rig
-
Gasoline engine:
-
3.3HP
-
Ignition method:
-
Recoil pull cord
-
Coring Mode:
-
Vertical Impact
-
Fuel consumption:
-
0.55L/H
-
Impact frequency:
-
1650 times/min
-
Impact energy:
-
35J-65J
-
Drill Pipe diameter:
-
34mm
-
Coring Depth:
-
10-15m
-
Core tube size:
-
54mm and 73mm
Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Xingda
-
Weight:
-
25 KG
-
Drilling Diameter:
-
34mm
-
Drilling Depth:
-
Max.15m
-
Product name:
-
portable core drilling rig
-
Gasoline engine:
-
3.3HP
-
Ignition method:
-
Recoil pull cord
-
Coring Mode:
-
Vertical Impact
-
Fuel consumption:
-
0.55L/H
-
Impact frequency:
-
1650 times/min
-
Impact energy:
-
35J-65J
-
Drill Pipe diameter:
-
34mm
-
Coring Depth:
-
10-15m
-
Core tube size:
-
54mm and 73mm
If you want to know more ,pls send us inquiry and we will give you best ideas
Product Description
Low Price Portable Mine Diamond Core Drilling Rig For 15m Core Sample Water Well
General Introduction
XINGDA XD-20T portable hydraulic core drilling rig is a small sampling drilling equipment widely used in plains/mountains/and areas with inconvenient transportation and energy. It has the advantages of compact structure, small footprint, light weight and convenient movement.Suitable for railway, water conservancy and other construction projects and geological sampling surveys in outdoor mountainous areas, geological core drilling rigs, small grouting hole blasting holes, etc.
Drilling rig use and scope of application
1. Engineering geological survey of structures such as railways, hydropower, transportation, bridges, and dam foundations.
2. Geological core drilling and physical surveys.
3. Drilling of small grout holes and blast holes.
4. Drilling of small water wells.
Technical parameters
|
Model
|
XD-20T
|
|
Gasoline engine
|
3.3HP
|
|
Ignition method
|
Recoil pull cord
|
|
Coring Mode
|
Vertical Impact
|
|
Fuel consumption
|
0.55L/H
|
|
Impact frequency
|
1650 times/min
|
|
Impact energy
|
35J-65J
|
|
Drill Pipe diameter
|
34mm
|
|
Coring Depth
|
10-15m
|
|
Core tube size
|
54mm and 73mm
|
|
weight(Kg)
|
25
|
If you want to know more ,pls send us inquiry and we will give you best ideas
FAQ
1. Are you a manufacturer, trading company or a third party?
We are a manufacturer and a trading company , our factory have more than 20 years experiences, our trading company have 6 years experiences.
2. What`s your terms of payment?
TT, 30-50% in deposit, the balance will be paid before delivery,we will send you photos of the products and packages before you pay the balance.
3. what`s your terms of delivery?
FOB,CIF,CFR
4. What about delivery time ?
Generally ,it ill take 7days after receiving your advance payment,the specific delivery time depends on the items and the quantity of your order.
5. What is your minimum order quantity?
Our minimum quantity for drillng machine is 1 set.
6. Is your price competitive?
A: Only good quality product we supply. Surely we will give you best factory price based on superior product and service.
7.What is the warranty of our machine ?
Our main machine enjoys a 1 year warranty, but not include any vulnerable parts on it. We could offer vulnerable parts at any time when you need.
8,Could you stick customers brand on the products?
We warmly welcome the OEM orders.
