Quick Details
-
Processor Core:
-
Dual Core
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Partaker
-
Model Number:
-
B6
-
Video Card:
-
Intel HD Graphics
-
CPU:
-
Processor 2955U
-
Color:
-
Black
-
TDP:
-
15W
-
Feature:
-
Fanless
-
Wireless:
-
Add 300M Wifi dual antennas
-
Ports:
-
VGA,HD-MI, LAN, 4USB3.0+2USB2.0
-
Case:
-
Aluminum Alloy Case
-
Memory Capacity:
-
1* SO-DIMM DDR3L 1333/1600, LPDDR3 1333/1600, max. 8GB RAM
-
Storage:
-
1* Msata SSD+1* 2.5 Inch HDD
-
Processor Main Frequency:
-
1.4Ghz
Quick Details
-
Use:
-
For Business
-
Hard Drive Type:
-
SSD
-
Video Memory Type:
-
With the main memory
-
Processor Core:
-
Dual Core
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Partaker
-
Model Number:
-
B6
-
Video Card:
-
Intel HD Graphics
-
CPU:
-
Processor 2955U
-
Color:
-
Black
-
TDP:
-
15W
-
Feature:
-
Fanless
-
Wireless:
-
Add 300M Wifi dual antennas
-
Ports:
-
VGA,HD-MI, LAN, 4USB3.0+2USB2.0
-
Case:
-
Aluminum Alloy Case
-
Memory Capacity:
-
1* SO-DIMM DDR3L 1333/1600, LPDDR3 1333/1600, max. 8GB RAM
-
Storage:
-
1* Msata SSD+1* 2.5 Inch HDD
-
Processor Main Frequency:
-
1.4Ghz
Product Description
|
Model
|
B6
|
|
|
General
|
|
|
|
CPU
|
Intel® Celeron® Processor 2980U (2M Cache, 1.60 GHz)
Intel® Pentium® Processor 3556U (2M Cache, 1.70 GHz) |
|
|
Operating System
|
Windows 7,8,10(OEM) or Linux
|
|
|
Core code
|
Haswell
|
|
|
Memory
|
1* SO-DDR3L SDRAM Memory Slot, Max to 8G DDR SDRAM
|
|
|
Storage
|
Support mSATA and SATA SSD; 2.5 inch laptop HDD; Can install 1pc HDD(2.5 inch) and 1pc SSD(mSATA) together
|
|
|
Chipset
|
Intel QS77 Express Chipset
|
|
|
BIOS
|
MI BIOS, ACPI supported. Support calls on function automatically
|
|
|
Network
|
Onboard RTL8111DL 10/100 / 1000Base T LAN
|
|
|
Audio
|
ALC662 chip, 6-channel sound
|
|
|
SATA
|
1 SATA3.0 interface, support for 6Gb / s; 1 SATA3 support 6Gb / s
|
|
|
MINI PCIE
|
2 MINI PCIE interface, full-height with Msata SSDs, half-height with wireless card
|
|
|
WiFi
|
150M WiFi or 300M WiFi with dual antenna(Optional)
|
|
|
CPU Performance
|
|
|
|
# of Cores
|
2
|
|
|
# of Threads
|
2
|
|
|
Processor Base Frequency
|
1.6 GHz/1.7 GHz
|
|
|
TDP
|
15 W
|
|
|
Lithography
|
22 nm
|
|
|
Graphics Specifications
|
|
|
|
Processor Graphics
|
Intel® HD Graphics
|
|
|
Graphics Base Frequency
|
200 MHz
|
|
|
Graphics Max Dynamic
Frequency |
1 GHz
|
|
|
I/O Ports
|
|
|
|
Display Port
|
1*VGA
1* HDMI |
|
|
USB Port
|
4* USB3.0
2* USB2.0 |
|
|
SATA Port
|
1* MSATA 3.0, 6Gb/s;
1* SATA 3.0, 6Gb/s |
|
|
Mini PCIE
|
1*MSATA SSD
1* WiFi Module |
|
|
Ethernet
|
1 RJ45 Gigabit LAN Port
|
|
|
Power input port
|
1*DC (IN) 12V
|
|
|
Power and Working Environment
|
|
|
|
Input
|
DC100-240V AC/50-60Hz
|
|
|
Output
|
DC 12V 3A
|
|
|
Operating Temperature
|
0/70 Centigrade(32F~140F)
|
|
|
Storage Temperature
|
(-20/+80)Centigrade
|
|
|
Relative Humidity
|
10%~90%(non-condensing)
|
|
|
Product Dimension&Details
|
|
|
|
Noise
|
Fanless System
|
|
|
Size
|
17*12*3.7CM
|
|
|
Weight
|
2KG
|
|
|
Shell
|
Black Color
|
|
|
Package Box
|
Neutral Color Box or INCTEL Color Box
|
|
|
Content
|
Mini PC device, Power Adapter, Desk base, Antennas
|
|
