- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YUGONG
-
Voltage:
-
110v 220V 380V
-
Dimension(L*W*H):
-
9600*2000*2100
-
Weight:
-
2500 KG
-
Marketing Type:
-
Hot Product 2023
-
Transport Package:
-
Plastic Film and Wooden Box Package
-
HS Code:
-
8441200000
-
EPC:
-
Simulated EPC
-
Specification:
-
KRAFT PAPER
-
Material Loading:
-
Hydraulic Loading
-
WAHT..APP:
-
0086-15515682190
Quick Details
-
Machine Type:
-
Bag Forming Machine
-
Bag Type:
-
Shopping Bag
-
Material:
-
paper bag
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YUGONG
-
Voltage:
-
110v 220V 380V
-
Dimension(L*W*H):
-
9600*2000*2100
-
Weight:
-
2500 KG
-
Marketing Type:
-
Hot Product 2023
-
Transport Package:
-
Plastic Film and Wooden Box Package
-
HS Code:
-
8441200000
-
EPC:
-
Simulated EPC
-
Specification:
-
KRAFT PAPER
-
Material Loading:
-
Hydraulic Loading
-
WAHT..APP:
-
0086-15515682190
Product Description
Why don't
contact me?
1. Provide most suitable machine model
2. Provide the most suitable construction plan
3. Get the latest discounts on purchases!
Note: Scan WhatsApp QR code
1. Open WhatsApp and tap Settings.
2. Tap the QR code icon displayed next to your name.
3. Click Scan > OK.
4. Hold the device and scan it at the top of the QR code.
5. Click Add Contact.
6. Open wealth~
Product advantage highlights
Specification
|
Model
|
YG220
|
YG330
|
YGB400
|
YGB550
|
|
Paper bag length
(Cutting length) |
191-430mm
|
280-510mm
|
280-600mm
|
380-770mm
|
|
Paper bag width
|
80-220mm
|
150-330mm
|
150-400mm
|
220-550mm
|
|
Paper bag
bottom width |
50-120mm
|
70-180mm
|
90-200mm
|
100-210mm
|
|
Paper thickness
|
45-130g/m2
|
60-150g/m2
|
70-150g/m2
|
80-150g/m2
|
|
Paper roll width
|
290-710mm
|
470-1000mm
|
510-1230mm
|
630-1550mm
|
|
Roll paper diameter
|
1300mm
|
1300mm
|
1300mm
|
1300mm
|
|
Machine MAX Speed
|
250pcs/min
|
200pcs/min
|
200pcs/min
|
150pcs/min
|
|
Paper bag speed
|
100-200 pcs/min
|
100-160 pcs/min
|
100-160 pcs/min
|
100-150 pcs/min
|
|
Machine power
|
380V
3 Phase 9kw |
380V
3 Phase 11kw |
380V
3 Phase 15.5kw |
380V
3 Phase 18.8kw |
|
Machine weight
|
5600kg
|
8000kg
|
9000kg
|
11000kg
|
|
Machine size
|
8600×2600×1900 mm
|
9500×2600×1900 mm
|
10700×2600×1900 mm
|
13000×2600×2000 mm
|
Our service
1.Whole process guidance
With more than 15 years of service experience,
we will spare no effort to provide support in selecting equipment, customizing production lines, improving supply chain, and post-optimization etc.
2.Provide a full set of construction method and equipment training
Provide design and construction solutions in terms of cost budget / progress improvement / quality control / safety management.
3.After-sales service system
Fully track the service system, focus on customer needs, first-class speed, skills, attitude, and provide support for customers' construction.
phone: 00 86 155 1568 2190
4.Support customization
Relying on our powerful flexible production line, we can give you the right to fully choose the mold, drive method, accessories upgrade, shell material, appearance color and Logo etc.
5.Extensive spare parts service
The spare parts warehouse of more than 50,000 square meters can meet the timely replacement and supplement of any wearing parts.
6.Support sea, land and air transportation
We can ship products to every corner of the world. If you need, we also support a series of tedious tasks such as customs clearance and tail end delivery.
Delivery
solid packaging
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
We also support air/sea/railway/automobile/bulk carrier, etc.;
Support from anywhere in China to anywhere in the world;
We can also help you to handle shipping/customs clearance/pay duties/delivery to your company and other services.
Our Company
Certification
We have passed CE, ISO, SGS certification! Better quality creates greater benefits for you!
Customer visit
We receive an average of 4 customers every week, visit and audit our factory, and negotiate business. There is a Chinese proverb:
It is always a pleasure to greet a friend from afar.
Factories and offices
More than 100,000 square meters of manufacturing and warehouse space More than 100 employees in the International Business Department.
FAQ & Contact
Q: How to select and determine the model?
A:
What types of paper bags are produced?
Size chart or drawing of paper bag
How much is the investment budget
Q: I just started to enter these industries? Don't know what to do?
A: We will assist you to choose a cost-effective machine; we will provide assistance in purchasing raw materials, equipment debugging, and later technical guidance.
Q: How can I ship these machines to my company after purchase?
A: We have a stable and cooperative freight forwarder and have rich experience. We can be responsible for the whole process of transportation/customs declaration/customs clearance/transportation, and transport the goods to your company.
Q: Can you tell us about your service and support throughout the process?
A: I think selling a machine is just the start of our partnership
1.We will provide technical solutions, product selection guidance, and related supporting equipment support before sales
(For example, to help you identify hot-selling products in the market to determine machine selection)
2.Provide regular feedback on manufacturing progress in production Pictures or videos
3.Provide machine testing after sale; free accessories; stable packaging; product shipping to your factory , customs clearance and shipping services we can also cover;
4.During production: continuous debugging of the machine; raw material supply etc.
