APPLICATION: AIR CONDITIONING
Brand: MASCOTOP
Original: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
- Product Details
- {{item.text}}
Quick Details
-
Shape:
-
ROUND
-
Terminal:
-
PINS or WIRES
-
Operation Class:
-
Class A:30000hrs, ClassB:10000hrs,Class C:3000hrs
-
Temperature Range:
-
-40℃ to 105℃
-
Outer Shell:
-
ROUND
-
Material of Case:
-
ALUMINUM or BAKELITE
Quick Details
-
Place of Origin:
-
China
-
Package:
-
Exporting Standard Packing. SINGLE BOX,PALLET
-
Certifications:
-
UL,CE,TUV,VDE ,CQC,ISI
-
Shape:
-
ROUND
-
Terminal:
-
PINS or WIRES
-
Operation Class:
-
Class A:30000hrs, ClassB:10000hrs,Class C:3000hrs
-
Temperature Range:
-
-40℃ to 105℃
-
Outer Shell:
-
ROUND
-
Material of Case:
-
ALUMINUM or BAKELITE
Product Description
Product Application
The capacitor has advantages of low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance ,and reliable safety with inner anti-explosion device,etc. It is applied in air conditioning,refrigerator,motor,compressor,it is helpful for motor's starting and running.
|
SPECIFICATIONS
|
|
|
|
|||
|
Ambient Temp.
|
-40~105(°C)
|
Rated Voltage
|
100~450VAC
|
|||
|
Capacitance Range
|
20~150uF
|
Testing Voltage:
|
T-T:2Un/2S
T-C:≥2200VAC/102S(VAC)
|
|||
|
Dissipation Factor
|
tanδ ≤ 0.002(100Hz)
|
Operating Frequency
|
50/60Hz
|
|||
|
Executing Standards : IEC60252,UL810.EN60252,VDE0560-8,GB3667.1-2005
Capacitance Tolerance:±3%or fulfilled upon request. |
|
|
|
|||
Main Features
1)Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
2) Individual colorful box will be designed according to customer's reuqirement
3) All sizes can be produced according to customer's request
4) OEM special design
5) With inner anti-explosion device
Certifications
Our Company
MAIN PRODUCTS
CBB65 AIR CONDITIONER CAPACITOR
CBB65 AIR CONDITIONER CAPACITOR
APPLICATION
: AIR CONDITIONING
Brand
: EAGLE
Original
: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
CBB65 AIR CONDITIONER CAPACITOR
APPLICATION
: AIR CONDITIONING
Brand
: STAR
Original
: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
CH85/CH86 HIGH VOLTAGE CAPACITOR FOR MICROWAVE OVEN
APPLICATION:
MICROWAVE OVENS
Brand:
MASCOTOP
Original:
CHINA
Good heat dissipation,high pressure value,small dimension and dielectric loss,high capacity precision,work stably with high voltage for long time.
CBB60 MOTOR RUN CAPACITOR
APPLICATION: MOTORS, PUMP, WASHING MACHINE,REFRIGERATOR
Original: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
CD60 STARTING CAPACITOR
APPLICATION: AIR CONDITIONING
Original: CHINA
Original: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
CBB61 MOTOR RUN CAPACITOR
APPLICATION: FAN,MOTORS
Original: CHINA
Low dissipation,high insulation resistance ,good self-healing character,anti-striking current,strong over-carrier capacity and steady electric performance
