Quick Details
-
Brand Name:
-
JTSPEEDWORK
-
Communication port:
-
TTL/USB
-
RF power:
-
0~26dBm (adjustable)
-
Operating current:
-
Peak current 200mA
-
Reading range:
-
0-2M(depend on the antenna and tags)
-
Reading tags:
-
multi-tag
-
Dimension:
-
30x26MM
-
Antenna port:
-
IPEX
Quick Details
-
Frequency:
-
860-960mhz
-
Protocol:
-
ISO 18000-6C
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JTSPEEDWORK
-
Communication port:
-
TTL/USB
-
RF power:
-
0~26dBm (adjustable)
-
Operating current:
-
Peak current 200mA
-
Reading range:
-
0-2M(depend on the antenna and tags)
-
Reading tags:
-
multi-tag
-
Dimension:
-
30x26MM
-
Antenna port:
-
IPEX
Product Description
|
Technical Parameters
|
|
|
|
Item No.
|
865-868MHz/920-925MHz/902-928MHz
|
|
|
Protocol
|
ISO 18000-6C/EPC C1G2
|
|
|
Chip
|
MagicRF M100
|
|
|
Reading rate
|
>300 times/sec
|
|
|
RF power
|
12~26±1dBm (adjustable)
|
|
|
Reading distance
|
0~2m (relate to antenna,tag and environment)
|
|
|
Write distance
|
0~30cm
|
|
|
Antenna interface
|
1 way IPEX
|
|
|
Communication Interface
|
Uart (TTL)
|
|
|
Power supply
|
5V
|
|
|
Working power consumption
|
<2W
|
|
|
RSSI
|
Support
|
|
|
FM mode
|
Fixed/hopping
|
|
|
SDK
|
Demo&C++,C#,JAVA,Android SDK
|
|
|
Physical Parameters
|
|
|
|
Dimensions
|
31.17(L)*26(W)*3(H)mm
|
|
|
Use Environment
|
|
|
|
Operating temperature
|
-40°C~+75°C
|
|
|
Storage temperature
|
-40°C~+85°C
|
|
|
Storage humidity
|
5-90%non-condensing(+25°C)
|
|
