Model
|
SHTF1350
|
|
Feeding Inlet
|
1350*200mm
|
|
Blade Shaft Diameter
|
450mm
|
|
Blade Quantity
|
24
|
|
Motor Power
|
37KW
|
|
Capacity
|
60 Pallets/Hour
|
|
Weight
|
3500KG
|
|
Blade Roll Diameter（mm）
|
600
|
|
|
Number of hammers
|
20
|
|
|
Feeding Inlet（mm）
|
300*1250
|
|
|
Feeding Speed(meters/min)
|
33
|
|
|
Main Motor Power（kw)
|
90
|
|
|
Processing Range(mm)
|
250*1250
|
|
|
Production Capacity（T/H)
|
300-500 Pallets/Hour
|
|
|
Discharge Conveyor Belt
|
10000mm
|
|
|
Feed Conveyor Belt
|
6000mm
|
|
|
Weight
|
7000kg
|
|
|
High Intensity Magnetic Machine
|
|
|
|
Specification
|
SH1300-600E
|
SH1300-600D
|
|
Feeding Inlet
|
1300*600mm
|
1300*600mm
|
|
Blade Roll Diameter
|
850mm
|
850mm
|
|
Blade Quantity
|
4 PCS
|
20 PCS
|
|
Blade Roll Speed
|
850R/Min
|
850R/Min
|
|
Max processing wood diameter
|
500mm
|
550mm
|
|
Wood Chipper Size
|
20-50mm
|
20-50mm
|
|
Production Capacity
|
15 Tons/Hour
|
15 Tons/Hour
|
|
Motor Power
|
160 KW Electric Engine
|
400HP Diesel Engine
|
|
Feeding Suspension Inverter Motor
|
7.5KW*1
|
7.5KW*1
|
|
Chain Plate Feeding Inverter Motor
|
11KW
|
11KW
|
|
Electric magnetic valve integrated
Oil Pump Motor
|
3KW
|
3KW
|
|
Conveyor Gear Motor Power
|
4KW
|
4KW
|
|
Weight
|
20Tons
|
20Tons
|
