HSY 1 ton ghost head chain electric hoist with hook nitchi lower chain hoist

HSY 1 ton ghost head chain electric hoist with hook nitchi lower chain hoist

FOB Reference Price: Get Latest Price

≥1 Pieces

US $200

≥5 Pieces

US $195

≥10 Pieces

US $185

≥20 Pieces

US $170

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Lift Speed:: 1T Single-chain 6.6m/min, 1T Double-chain 3.4m/min, 2T Single-chain 6.6m/min, 2T Double-chain 3.4m/min, 3T Single-chain 5.6m/min, 3T Double-chain 3.3m/min, 3T Triple-Chain 2.2m/min, 5T 2.8m/min, 10T 2.8m/min

Weight (KG):: 50 kg

Shell:: Aluminum alloy shell, overall sealed structure.

Paramagnetic brake:: Power off while braking

Limit Switch:: Automatic stop to prevent the chain from exceeding and ensure safety.

Chain:: G80 chain with four times experimental load.

Hook:: Hot-forged, rotatable 360°, with safety tongue.

Support bracket:: Combination of two steel plates

Transformer:: 24V/36V voltage converter

Electromagnetic contactor:: Available for high frequency use

Mechanical brake:: Dual braking system

Reverse protection device:: Special wire installation

Quick Details

Warranty:: 1 Year

Place of Origin:: Hebei, China

Brand Name:: HUGO

Lift Speed:: 1T Single-chain 6.6m/min, 1T Double-chain 3.4m/min, 2T Single-chain 6.6m/min, 2T Double-chain 3.4m/min, 3T Single-chain 5.6m/min, 3T Double-chain 3.3m/min, 3T Triple-Chain 2.2m/min, 5T 2.8m/min, 10T 2.8m/min

Weight (KG):: 50 kg

Shell:: Aluminum alloy shell, overall sealed structure.

Paramagnetic brake:: Power off while braking

Limit Switch:: Automatic stop to prevent the chain from exceeding and ensure safety.

Chain:: G80 chain with four times experimental load.

Hook:: Hot-forged, rotatable 360°, with safety tongue.

Support bracket:: Combination of two steel plates

Transformer:: 24V/36V voltage converter

Electromagnetic contactor:: Available for high frequency use

Mechanical brake:: Dual braking system

Reverse protection device:: Special wire installation

HSY 1 ton ghost head chain electric hoist with hook nitchi lower chain hoist

Product Description

This machine adopts high strength aluminum alloy body, beautiful appearance, compact body, small volume, light weight, using two gear transmission, high-speed level for helical gear transmission, so the transmission is smooth, low noise; the main parts of this machine are made of high alloy steel materials, and through a number of special heat treatment process, with high strength, good wear resistance, etc., the upper and lower hooks are made of high strength alloy steel, after strengthening heat treatment with high toughness, even if the body caused by overload damage, the hooks will only plastic deformation, but will not occur brittle fracture.

Our Advantages

MANUAL SPORTS CAR

The roller shaft is equipped with a rolling bearing, high walking efficiency, small push-pull pull-off force

G100 LEVEL CHAIN

Intermediate frequency quenching heat treatment

Higher safety factor and longer life

MANGANESE STEEL HOOK

Not easy to break after hot forging

TRANSFORMER

Transformer inside the control box

Prevent the switch cable from damage and leakage

①Aluminum alloy shell, solid and light, with special heat sink, fast heat dissipation, can work continuously.②Limit switch: There is a limit switch device for lifting up and down, which will automatically stop when using and prevent the
chain from exceeding to ensure safety.
③Hook: hot forged, excellent strength, not easy to break, the lower hook can be rotated 360 °, with a safety tongue to ensure safe
operation.
④Chain protection bag: prevent the chain from falling down or sticking to the dirt.
⑤G80 chain, medium frequency quenching and heat treatment, low wear, anti-corrosion, 4 times experimental load.
⑥Double brakes: electromagnetic brake, mechanical brake, to ensure absolute safety and reliability when braking.
⑦Reverse protection device: Special wire device that prevents the control circuit from operating when the power line is wrong.
⑧Handle: waterproof button switch, lightweight and durable, 36V low voltage.
⑨Each unit is tested three times before leaving the factory to ensure that the product is qualified to leave the factory, and the
safety factor is 1.25 times of the general product.
⑩With CE certification.

Specification

item	value
Applicable Industries	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
Showroom Location	None
Condition	New
Place of Origin	China
	Hebei
Brand Name	HUGO
Usage	Construction Hoist
Power Source	Electric
Sling Type	Chain
Lift Speed	1T Single-chain 6.6m/min, 1T Double-chain 3.4m/min, 2T Single-chain 6.6m/min, 2T Double-chain 3.4m/min, 3T Single-chain 5.6m/min, 3T Double-chain 3.3m/min, 3T Triple-Chain 2.2m/min, 5T 2.8m/min, 10T 2.8m/min
Warranty	1 Year
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Marketing Type	New Product 2020
Warranty of core components	1 Year
Core Components	Motor
Weight (KG)	50kg
Shell	Aluminum alloy shell, overall sealed structure.
Paramagnetic brake	Power off while braking
Limit Switch	Automatic stop to prevent the chain from exceeding and ensure safety.
Chain	G80 chain with four times experimental load.
Hook	Hot-forged, rotatable 360°, with safety tongue.
Support bracket	Combination of two steel plates
Transformer	24V/36V voltage converter
Electromagnetic contactor	Available for high frequency use
Mechanical brake	Dual braking system
Reverse protection device	Special wire installation
