Quick Details
-
Scan Speed:
-
200times/sec
-
Brand Name:
-
alacrity
-
Place of Origin:
-
Guangdong, China
-
Application:
-
Logistics Industry/supermarket/warehouse/etc
-
Weight:
-
350g
-
Light source:
-
LED Lights
-
Feature:
-
Handheld 2d BT Barcode Scanner
-
Color:
-
sliver+black
-
Interface:
-
Wireless BT Transmission
-
Scan Mode:
-
Handheld/automatic/button/SCANNING
-
Battery:
-
1800mAh
-
Material:
-
ABS
-
Scan type:
-
2D CMOS
Quick Details
-
Type:
-
Handheld
-
Scan Element Type:
-
CMOS
-
Optical Resolution:
-
644X488
-
Scan Speed:
-
200times/sec
-
Brand Name:
-
alacrity
-
Place of Origin:
-
Guangdong, China
-
Application:
-
Logistics Industry/supermarket/warehouse/etc
-
Weight:
-
350g
-
Light source:
-
LED Lights
-
Feature:
-
Handheld 2d BT Barcode Scanner
-
Color:
-
sliver+black
-
Interface:
-
Wireless BT Transmission
-
Scan Mode:
-
Handheld/automatic/button/SCANNING
-
Battery:
-
1800mAh
-
Material:
-
ABS
-
Scan type:
-
2D CMOS
Products Description
3 in 1
This product can work with USB wired mode. The wire length is 1.5M
2.4Ghz wireless mode can connect ipad .PC.terminal etc
BT wireless can be connected to mobile phones. Press and hold the scanner button for 8sec to click BT to pair
Compatible with multiple systems
The scanner is compatible with IOS.Android.Windows.Mac OS.Linux.
terminal: IPad smartphone.laptop.PC.cash register
The product supports three modes of BT: SPP.HID.SPP
drop strength
The scanner is made of ABS material. It can withstand 1.5M high-altitude drop
Large capacity battery
The wireless scanning lianxu instrument adopts 1800mAh high-capacity lithium-ion battery. It can work continuously for 4-6hrs in high power consumption. It adopts 16MB memory. It can use storage mode to store 100000 barcode
.
The product button can work continuously for 10,000 times
Product parameters
|
Product specification
|
|
|
|
|
||||
|
Working Temperature
|
|
32°F to 104°F/0°C to 40°C
|
|
|
||||
|
Storage Temperature
|
|
-40°F to 140°F/-40°C to 60°C
|
|
|
||||
|
Humidity
|
|
5% to 95% relative humidity (no condensation)
|
|
|
||||
|
Image Sensor
|
|
644X488 pixels (optional)
|
|
|
||||
|
Electrostatic discharge
|
|
In line with 15KV air discharge and 8KV contact discharge requirements
|
|
|
||||
|
Wireless protocol
|
|
BT.2.4G
|
|
|
||||
|
Memory
|
|
16 MB
|
|
|
||||
|
Processor
|
|
ARM Cortex 32bits
|
|
|
||||
|
BT version
|
|
BT 4.1Module
|
|
|
||||
|
Supported symbologies:
|
|
1D: Codabar,Code 11, Code93,MSI,Code 128,UCC/EAN-128,Code 39,EAN-8, EAN-13,UPC-A,ISBN,Industrial 25,Interleaved 25, Standard
25,2/5 Matrix |
|
|
||||
|
Supported symbologies:
|
|
2D:QR,DataMatrix,PDF417,Aztec,Hanxin , Micro PDF417(option)
|
|
|
||||
|
Indicator
|
|
: Led、Buzzer、Vibrator(option)
|
|
|
||||
|
Battery capacity
|
|
1800mA
|
|
|
||||
|
Charging voltage/current
|
|
5V/1A
|
|
|
||||
|
Endurance
|
|
1D≤24H 2D≤16H（5seconds/scan）
|
|
|
||||
|
Charge time
|
|
≤4hours
|
|
|
||||
