SPECIFICATION
|
|
|
|
|
||||
|
Model
|
|
TZ-600 RC
|
|
|
||||
|
Max dritling depth (m)
|
|
600
|
|
|
||||
|
Drilling diameter (mm)
|
|
105-450
|
|
|
||||
|
Air pressure (Bar)
|
|
1.6-6
|
|
|
||||
|
Air consumotion (m3/min)
|
|
16-75
|
|
|
||||
|
Drill Pipe Length (m)
|
|
3
|
|
|
||||
|
Recommend Drill Pipe
|
|
102
|
|
|
||||
|
Main shaft pressure (T)
|
|
7
|
|
|
||||
|
Lifting force (T)
|
|
28
|
|
|
||||
|
Fast lifting speed (m/min)
|
|
29
|
|
|
||||
|
Fast forwarding speed
|
|
28
|
|
|
||||
|
Rotary torque (Nm)
|
|
12000/6000
|
|
|
||||
|
Rotary speed (R/min)
|
|
93/186
|
|
|
||||
|
Winch liftting force (T)
|
|
1.5
|
|
|
||||
|
Leg Stroke (m)
|
|
1.6
|
|
|
||||
|
Drilling efficiency (m/h)
|
|
10-35
|
|
|
||||
|
Drilling angle (°)
|
|
40-90
|
|
|
||||
|
Walking Speed (Km/h)
|
|
3
|
|
|
||||
|
Grade ability (°)
|
|
21
|
|
|
||||
|
Dimension（m）
|
|
7.9x2.25x3.1
|
|
|
||||
|
Weight （T）
|
|
12
|
|
|
||||
