Quick Details
-
Brand Name:
-
Shangjin
-
Hot Dimension:
-
1200*1200mm
-
Max Fusing Width:
-
1100mm
-
Temperature:
-
0-220°
-
Power:
-
14KW
-
Rubber Shaft Diameter:
-
100mm*2
-
Speed:
-
2-15m/min
Quick Details
-
Weight (KG):
-
600
-
Marketing Type:
-
Hot Product 2021
-
Place of Origin:
-
Shanghai ,China
-
Brand Name:
-
Shangjin
-
Hot Dimension:
-
1200*1200mm
-
Max Fusing Width:
-
1100mm
-
Temperature:
-
0-220°
-
Power:
-
14KW
-
Rubber Shaft Diameter:
-
100mm*2
-
Speed:
-
2-15m/min
|
Model |
HP-600A/AL |
HP-900A/AL |
HP-1200A/AL |
||
|
Power Supply |
3P/380V |
||||
|
Motor |
180W |
||||
|
Power |
7.2KW |
12KW |
14.4KW |
||
|
Max Pressure |
6kg/cm² |
||||
|
Temperature |
0-220 ℃ |
||||
|
Fusing Width |
600mm |
900mm |
1200mm |
||
|
Fusing Time |
10-24sec |
||||
|
L × W × H Dimensions ( mm ) |
3150× 900 × 1200 |
3150× 1500 × 1200 |
3150× 1800 × 1200 |
||
|
L × W × H Packing Volume( mm ) |
1350× 1180/1480 × 1400 1000× 810 × 1290 |
1650× 1180/1480 × 1400 1300× 810 × 1290 |
1950× 1180/1480 × 1400 1600× 810 × 1290 |
||
|
N.W/G.W |
500/650 |
600/750 |
700/850 |
||
Feature:
1, Continuous fusing system increases the productivity.
2, Equipped with the wheels for convenient mobility.
3, PCB and micro switch control the upper and lower belts automatically and extends duration of the belt.
4, Pressure rollers are made by silicone,which ensure the power of pressure giving is stable and equal.
5, Electronic temperature constant temperature control system, temperature accurately.
6, There are 6 heaters to distribute the heat evenly and can be used to all fabrics.
7, With the cooling fan and mesh conveyor belt,which has the best cooling effect.
8, Equipped with automatic cooling timing shutdown system.
9, Standard with strong spring-pressure mechanism.
10, Special-designed clean rod to clean the belt completely,and it is easy for replacement once the rod gets dirty.
11, Optional:HP-600/900/1200A:Air(Pneumatic)Pressure;HP-600/900/1200L:Longer bottom belt.
