> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
1470*680*35mm
-
Solar cell:
-
Poly 156*156 Cell
-
Warranty:
-
25 Years Output Power Guarantee
-
Frame:
-
Anodized Aluminium Alloy
-
Color:
-
Standard/Full Black/Super Black
-
Connector:
-
MC4
-
Cable:
-
4mm2
-
Application:
-
Boat
-
OEM:
-
Accaptable
-
Maximum System Voltage:
-
DC (IEC) / 600V DC (UL)
Quick Details
-
Type:
-
Standard Solar Panel
-
Brand Name:
-
Futuresolar
-
Model Number:
-
FSM150P-36
-
Place of Origin:
-
Fujian, China
-
Panel Dimensions:
-
1470*680*35mm
-
Solar cell:
-
Poly 156*156 Cell
-
Warranty:
-
25 Years Output Power Guarantee
-
Frame:
-
Anodized Aluminium Alloy
-
Color:
-
Standard/Full Black/Super Black
-
Connector:
-
MC4
-
Cable:
-
4mm2
-
Application:
-
Boat
-
OEM:
-
Accaptable
-
Maximum System Voltage:
-
DC (IEC) / 600V DC (UL)
Product Description
|
Module
|
FSM150P-36
|
FSM155P-36
|
FSM160P-36
|
FSM165P-36
|
FSM170P-36
|
||||
|
Rated Maximum Power at STC
|
150
|
155
|
160
|
165
|
170
|
||||
|
Open Circuit Voltage(Voc/V)
|
22.4
|
22.5
|
22.6
|
22.7
|
22.8
|
||||
|
Maximum Power Voltage(Vmp/V)
|
17.5
|
17.6
|
17.7
|
17.8
|
17.9
|
||||
|
Short Circuit Current(Isc/A)
|
9.05
|
9.28
|
9.52
|
9.71
|
9.93
|
||||
|
Maximum Power Current(Imp/A)
|
8.63
|
8.81
|
9.04
|
9.27
|
9.50
|
||||
|
Module Efficiency(%)
|
14.88
|
15.38
|
15.87
|
16.37
|
16.87
|
||||
|
Power Tolerance
|
-0~+3%
|
|
|
|
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m
2
,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|
||||
Detailed &Production
Glass
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
Frame
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
Who Is Futuresolar
Payment
|
Payment Terms
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L (
Not Suitable for Solar System Orders
)
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
|
DDP
|
|
|
|||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight (
Not Suitable for Solar System Orders
)
|
|
|
|||
|
|
West Union
|
Amount lower than 5000usd
|
|
|
|||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
|
|||
