Quick Details
-
Item:
-
Road paint high pressure water remove cleaning machine
-
Usage:
-
To clean the road surface old line
-
Clean type:
-
Alloy knife remover
-
0ptical cleaning way:
-
Milling planing/steel brush/Alloy knife
-
After Warranty:
-
Online support
-
Warranty Service:
-
Spare parts
-
Service:
-
Field maintenance and repair service
Quick Details
-
Place of Origin:
-
China
-
Weight:
-
230 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Item:
-
Road paint high pressure water remove cleaning machine
-
Usage:
-
To clean the road surface old line
-
Clean type:
-
Alloy knife remover
-
0ptical cleaning way:
-
Milling planing/steel brush/Alloy knife
-
After Warranty:
-
Online support
-
Warranty Service:
-
Spare parts
-
Service:
-
Field maintenance and repair service
Asphalt road marking line removal machine Application
| 1.JL-PHQ alloy knife road marking remover is specialized for clearing away the broken, stained and wrong marking lines. |
| 2. Alloy knife |
| 3. Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble. |
Asphalt road marking line removal machine Technical Data
|
Model |
JL-PHQ |
|
Engine |
Kohler or Briggs 10.5 HP gasoline engine |
|
Removal grinding head |
Tungalloy cutter, 24 teeth for thermoplastic marking lines, 48 teeth for cold paint marking lines |
|
Removal depth control |
Accurate pitch depth adjuster |
|
Removal pressure control |
Dial instruction pressure adjuster |
|
Clutch protective device |
Automatic clutch equipment |
|
Dust collector joint |
Φ 76 mm |
|
Operation method |
Pull, push, wave |
|
Removal width |
180 mm - 620 mm |
|
Dimensions (L*W*H) |
1240 mm × 780 mm × 1100 mm |
|
Weight |
230 kg |
|
Optional system |
Dust collector and roll booster |
|
|
Old Road Marking Paint Removal Machine Features
| Removal cutter : Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble. |
| Depth adjuster: Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs. |
| Pressure adjuste r: According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted. |
| Protective device : Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life. |
| Emergency stop device : Equipped with emergency stop switch, which can stop the machine in short time. |
| Parking device : Convenient foot control parking system makes the machine in safety condition in any time. |
| Operation : Forward, back off, left or right operated freely. |
|
Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment; the four-wheel structure makes the whole machine work more stable, and operation more convenient. |
Features
| Removal cutter : Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble. |
| Depth adjuster: Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs. |
| Pressure adjuste r: According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted. |
| Protective device : Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life. |
| Emergency stop device : Equipped with emergency stop switch, which can stop the machine in short time. |
| Parking device : Convenient foot control parking system makes the machine in safety condition in any time. |
| Operation : Forward, back off, left or right operated freely. |
|
Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment; the four-wheel structure makes the whole machine work more stable, and operation more convenient. |
Features
| Removal cutter : Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble. |
| Depth adjuster: Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs. |
| Pressure adjuste r: According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted. |
| Protective device : Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life. |
| Emergency stop device : Equipped with emergency stop switch, which can stop the machine in short time. |
| Parking device : Convenient foot control parking system makes the machine in safety condition in any time. |
| Operation : Forward, back off, left or right operated freely. |
|
Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment; the four-wheel structure makes the whole machine work more stable, and operation more convenient. |
