Quick Details
-
Max. Loading Capacity:
-
16000 cubic meter
-
Weight (KG):
-
1000 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FUYI
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
Have different models
-
Power (kW):
-
100 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine material:
-
Stainless steel,carbon steel
-
Usage:
-
Chemical Industry
-
Motor Brand:
-
Siemens
-
Control:
-
Manual or automatic
-
Power:
-
3-110kw
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
Quick Details
-
Barrel Volume (L):
-
6000
-
Max. Loading Volume (L):
-
10000 L
-
Range of Spindle Speed(r.p.m):
-
30 - 100 r.p.m
-
Max. Loading Capacity:
-
16000 cubic meter
-
Weight (KG):
-
1000 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FUYI
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
Have different models
-
Power (kW):
-
100 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine material:
-
Stainless steel,carbon steel
-
Usage:
-
Chemical Industry
-
Motor Brand:
-
Siemens
-
Control:
-
Manual or automatic
-
Power:
-
3-110kw
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
Products Description
DH series dry type roller press granulator
The working principle of dry granulation is mainly to extrude the material between two reverse rotating rollers by external force, and use dry roller granulation technology to crush and screen the material with moisture content ≤1%, so that the massive material meets the application requirements of particles. In the process of rolling, the actual density of the material can be increased by 1.5~3 times to reach a certain particle strength requirement.
(1) quantitative screw feeder
(2) forced feeder
(3) coupling
(4) roller
(5) hydraulic station
Structure
Process Technology
Technology Process
|
Model
|
DH240
|
DH360
|
DH450
|
DH650
|
DH850
|
DH1050
|
|||||
|
Roller diameter(mm)
|
φ240
|
φ360
|
φ450
|
φ650
|
φ850
|
φ1050
|
|||||
|
Valid usable width of roller(mm)
|
100-160
|
170-230
|
190-280
|
290-330
|
420-450
|
450-500
|
|||||
|
Rotation rate(rpm)
|
It can be adjusted on site according to different material characteristic.
|
|
|
|
|
|
|||||
|
Maximum thickness of flakes(mm)
|
4
|
8
|
12
|
16
|
32
|
45
|
|||||
|
Flakes output(t/h)
|
0.5-1.5
|
1.3-2.3
|
2.5-3.5
|
5.0-7.0
|
12-22
|
22-45
|
|||||
|
Finished product granule size(mm)
|
2-5
|
2-5
|
2-5
|
2-5
|
2-5
|
2-5
|
|||||
|
Finished product output(t/h)
|
0.3-0.75
|
0.9-1.3
|
1.8-2.5
|
3.5-4
|
5-8
|
10-16
|
|||||
|
Compactor power(KW)
|
22
|
30-37
|
55-75
|
110-132
|
220-225
|
400-550
|
|||||
|
Total power for whole line(KW)
|
55
|
55
|
90
|
175
|
400
|
850
|
|||||
|
External dimension(mm)
|
2300*1700*1860
|
2350*2000*2600
|
2600*2200*2900
|
3600*2800*3200
|
5000*3800*4100
|
7000*5000*6000
|
|||||
|
Compactor weight(t)
|
5
|
7
|
10
|
21
|
46
|
85-95
|
|||||
Related ancillary equipment
Scene display
Corporate Profile
Jiangsu Fuyi Machinery Technology Co., Ltd. was founded in March 2006, is located in No. 212,Huaxing Road ,Jintan Economic Development Zone,Changzhou city, Jiangsu province. Jiangsu Fuyi Machinery Technology Co., Ltd., Changzhou Fuyi drying Equipment Co., Ltd., Jiangsu Fuyi Automation Equipment Co., Ltd. together production and manufacture.
Company is one professional enterprise, specialized in the developing and manufacturing of dry granulating equipment, drying equipment, dynamic calcinations equipment , etc. By Absorbing advanced drying & granulating technology at home and abroad, we improve the technology of rotary flash dryer and dry granulator.
