Quick Details
-
Raw material:
-
Silicone raw gum
-
Apperance:
-
Colorful solid rubber
-
Color:
-
Black, green, bule , red, brown or custimized
-
Hardness:
-
30-90 shore A
-
Name:
-
Flame Retardant Silicone Rubber
-
Usage:
-
Sealing molding part material
-
Features:
-
fire retardant silicone
-
Temperature range:
-
-60℃~+250℃
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
eson
-
Model Number:
-
cusmized
-
Raw material:
-
Silicone raw gum
-
Apperance:
-
Colorful solid rubber
-
Color:
-
Black, green, bule , red, brown or custimized
-
Hardness:
-
30-90 shore A
-
Name:
-
Flame Retardant Silicone Rubber
-
Usage:
-
Sealing molding part material
-
Features:
-
fire retardant silicone
-
Temperature range:
-
-60℃~+250℃
High Tensile Strength 80 Shore A Silicone Rubber Compound
Description:
Flame retardant silicone material has excellent high and low temperature resistance, electrical insulation, flame retardant, widely used in the wire and cable industry, such as high and low temperature resistance, high insulation requirements of the wire and cable, nuclear power plant wire and cable cladding materials are used in the silicone material.
Features:
1. Flame Retardant Silicone Rubber have Good flame retardant property,
2. Good machining performance,
3. Good physical performance
4. Aging resistance
5. High and low temperature resistance
6. One component room temperature cured silicone sealant, cured rubber layer is elastomer;
7. Neutral curing, non-corrosive to most metals;
8. Excellent alternating heat and cold resistance, aging resistance and electrical insulation;
9. The rubber layer has excellent properties of moistureproof, seismic, corona resistance and leakage resistance.
Typical applications:
Eson Flame Retardant Silicone Rubber mechanical bonding and sealing of electronic and electrical components such as power supply, photovoltaic modules, communication equipment, etc., as well as bonding and fixing of electronic components. Other metal, plastic, glass and other adhesive sealing with flame retardant requirement.
|
Flame retardant silicone rubber (HCR) |
||||||
|
Application: |
all kinds of flame retardant products . |
|||||
|
Key features : |
halogen -free flame retardant ,excellent flame retardancy ,good thermal resistance ,,pass ROHS ,REACH. |
|||||
|
Test : |
50% DBPMH,add 1%, 175℃ x 5min x 15MPA |
|||||
|
Press cure :170 ℃* 20 min |
Post cure :200℃*4hrs |
|||||
|
Typical Properties |
Unit |
Test Methods |
150Z |
160Z |
170Z |
180Z |
|
Density |
g/cm3 |
D-792 |
1.4 |
1.45 |
1.45 |
1.42 |
|
Hardness |
Shore A |
D-2240 |
50 |
60 |
70 |
80 |
|
Tensile strength |
Mpa |
D-412 |
5 |
5 |
5 |
5 |
|
Elongation |
% |
D-412 |
360 |
260 |
240 |
200 |
|
Tear Strength |
KN/M |
D-624-B |
11 |
12 |
12 |
14 |
|
Plasticity |
/ |
D624 |
210 |
230 |
260 |
280 |
|
Flame Retardant Level |
/ |
GBT10707-2008 |
V0 |
|||
FQA:
Can you customized Flame Retardant Silicone Rubber to us?
Yes, pls provided your technical required data sheet and application for we reference. We also provide different
hardness and different silicone types to meet customer demand.
What is your lead time?
Its depend on the what you need is our generally grade or not. If it is common grade we can prepare 10T within 5 days.
Can you add curing agent for us? How about the material color?
After adding the curing agent the shift time will be shorter, we glad to added the curing agent or the color pigment if required.
