Quick Details
-
Warranty:
-
1years
-
Brand Name:
-
JSG DC PUMP
-
Model Number:
-
BD-08AB-PWM/BD-08VB-PWM
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
N/M
-
Cable Length:
-
20cm (can custom)
-
Outlet Size:
-
OD:8.3mm,ID:4.5mm
-
Power:
-
24-50W
-
motor:
-
DC Brushless motor (BLDC)
-
Item:
-
Mini Piston compressor air vacuum pump with PWM
-
Motor:
-
dc brushless motor(long life span)
-
Pump head material:
-
Aluminum alloy
-
diaphragm material:
-
High temperature resistance
-
Medium:
-
air/gas
-
Working time:
-
Continuous
-
Feature:
-
Oilless, High pressure, High flow
-
Theory:
-
Piston Pump
-
MOQ:
-
1 PCS
-
Certification:
-
RoHS CE ISO9001
Quick Details
-
Application:
-
Other, Automotive Industry, Metal and Equipment Manufacturers
-
Pressure:
-
High Pressure
-
Voltage:
-
12V/24V
-
Warranty:
-
1years
-
Brand Name:
-
JSG DC PUMP
-
Model Number:
-
BD-08AB-PWM/BD-08VB-PWM
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
N/M
-
Cable Length:
-
20cm (can custom)
-
Outlet Size:
-
OD:8.3mm,ID:4.5mm
-
Power:
-
24-50W
-
motor:
-
DC Brushless motor (BLDC)
-
Item:
-
Mini Piston compressor air vacuum pump with PWM
-
Motor:
-
dc brushless motor(long life span)
-
Pump head material:
-
Aluminum alloy
-
diaphragm material:
-
High temperature resistance
-
Medium:
-
air/gas
-
Working time:
-
Continuous
-
Feature:
-
Oilless, High pressure, High flow
-
Theory:
-
Piston Pump
-
MOQ:
-
1 PCS
-
Certification:
-
RoHS CE ISO9001
Use for Air/Vacuum Pump Parameter
| Name | Model | Voltage |
Connection Type |
No-load
Current |
Positive Pressure |
Negative Pressure |
Max Flow |
| Air pump | BD-08AB-PWM | 24V | in parallel | ≤4.5A | ≥0.7Mpa | / | ≥80L/min |
| Vacuum pump | BD-08VB-PWM |
in parallel |
≤4.5A | / | ≥0.085Mpa | ≥70L/min | |
| in series | ≤4.5A | / | ≥0.095Mpa | ≥30L/min |
Remark:
1. "AB"means air pump with brushless motor, "VB"means vacuum pump with brushless motor
2. Dear customer, for custom parameters , please refer to the third table
3. Pressure unit conversion:
10kpa=0.01Mpa=0.1bar=100mbar=1.45psi=75mmHg=1019.7kgf/m2
100kpa=0.1Mpa=1bar=1000mbar=14.5psi=750mmHg=10197kgf/m2
4.Because of the increase in raw materials, the sample price increased to $200.
General Specification
| Dimention | 134x81x50mm |
| Inlet/Outlet | ID:8.0mm/OD:5.0mm |
| Weight | 700g |
| Materials | Pump head Aluminum alloy, membrane FKM, valve FKM |
| Working Mode | Continuous |
| Motor | Brushless DC Motor |
| Life time | 5000H-10000H |
| Environment Temperature range | 5-50℃ |
| Ambient humidity range | <85% RH |
Dimention
Product Details
Typical Appliaction
More Appliaction
1.Mounter
2.Laboratory
3.Ventilator
4.Gas analysis
5.Leak detector
6.Food equipment
7.Robotics field
8.New energy field
9.Medical equipment
10.Pressurized spray
11.Rehabilitation machine
12.Environmental monitoring
13.Portable oxygen generator
14.Cosmetic slimming equipment
15.Large suction packaging machine
16.Environmental protection equipment
......
Custom Parameters
| Motor | Brushless DC Motor-single head | Brushless DC Motor-double head |
| Lifetime | 5000-10000H | 5000-10000H |
| Voltage | 24V | |
| Positive Pressure range | 100-700kpa | |
| Negative Pressure range | 80-97kpa | |
| Air flow range | 40-80L/min | |
| Working Mode | Continuous | |
1.Pressure unit conversion:
10kpa=0.01Mpa=0.1bar=100mbar=1.45psi=75mmHg=1019.7kgf/m2
100kpa=0.1Mpa=1bar=1000mbar=14.5psi=750mmHg=10197kgf/m2
2.If you are interested in our products, please
contact us
Brush motor
| Lead angle | Two(+,-) |
Brushless motor
| 2 Wire | Red(+),Black(-) |
| 3 Wire | Red(+),Black(-),Green(PWM) |
| 4 Wire | Red(+),Black(-),Green(PWM),Yellow(tachometere) |
