- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
TOP BRAND
-
Travel Speed:
-
2/4/9.6km/h
-
Grade Ability:
-
25%
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
SINOMADA
-
Dimension(L*W*H):
-
5700*2400*3000mm
-
Drum diameter:
-
1500mm
-
Exciting Force:
-
-
-
Marketing Type:
-
New Product 2021
-
After Warranty Service:
-
Online support
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
85kw
-
Weight:
-
21/25 ton
-
Engine Brand:
-
TOP BRAND
-
Travel Speed:
-
2/4/9.6km/h
-
Grade Ability:
-
25%
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
SINOMADA
-
Dimension(L*W*H):
-
5700*2400*3000mm
-
Drum diameter:
-
1500mm
-
Exciting Force:
-
-
-
Marketing Type:
-
New Product 2021
-
After Warranty Service:
-
Online support
21TON 25TON Three Wheel Static Roller
LYJ2125 with Good Quality
Pearl Wang
Mobile/Whatsapp/Wechat:+86 17369285626
Instagram/Facebook:Pearl Wang
e-mail: pearl@
sinomada.com
LTJ2125,LTJ1821 The machines are heavy-duty static three wheel road rollers.With their dead weight, they compact cohesive and non-cohesive materials, such as gravel, sand stone mixture,sandy soil,and asphalt concrete. They are universal compaction equipments for highway, municipal road, parking area and industry ground etc, medium and large-scale construction projects.
*Steady quality,serial products cover wide applications.
| MODEL | LYJ2125 | LYJ1821 | |
| Operating mass | |||
| Without ballast | Kg | 21000 | 18000 |
| With ballast | 25000 | 21000 | |
| Front linear load | |||
| Without ballast | N/cm | 575 | 510 |
| With ballast | 650 | 565 | |
| Read linear olad | 1200 | 1056 | |
| Without ballast | N/cm | 1358 | 1226 |
| With ballast | |||
| Travel speed | |||
| 1st gear | Km/h | 2.0 | 2.0 |
| 2nd gear | 4.0 | 4.0 | |
| 3rd gear | 9.6 | 9.6 | |
| Grade ability | % | 25 | 25 |
| Turning radius | mm | ||
| Inside | 5180 | 5180 | |
| Outside | 7500 | 7500 | |
| Steering angle | ±35 | ±35 | |
| Overall length | mm | 5700 | 5700 |
| Overall width | mm | 2400 | 2400 |
| Overall height | mm | 3000 | 2975 |
| Front wheel size | mm | ||
| Width | 1680 | 1680 | |
| Diameter | 1500 | 1450 | |
| Rear wheel size | mm | ||
| Width | 650 | 650 | |
| Diameter | 1700 | 1650 | |
| Wheelbase | mm | 2945 | 2945 |
| Ground clearance | mm | 370 | 370 |
| Diesel model | YC6B120 | YC6B120 | |
| Diesel power | Kw | 85 | 85 |
| Diesel speed | r/min | 2000 | 2000 |
| Fuel tank capacity | L | 200 | 200 |
| Electrical voltage | V | 24 | 24 |
| Hydraulic tank capacity | L | 82 | 82 |
