Quick Details
-
Model Number:
-
LZJ-CL-330
Quick Details
-
Power:
-
Electronic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LZJ
-
Model Number:
-
LZJ-CL-330
Product Application
This machine is formed by two different diameter rollers and follows specification to install jump plates at bike’s seat post , pedals, bars, luggage carries, with load set to this tester. Adjust the distance between front and rear wheel base on the standard for complete cycles, constantly rotate the wheel by 7-27km/hr so that the bike is supposed to maintain its normal function, and no part damage or crack is found. For brake test, follow the specification specified roller’s friction coefficient, wind speed and water-spray amount of loaded brake holding handle to test the performance and judge bike's performance under the defined frequency.
Specification
| Torque sensor capacity | 0-100N.M |
| Force sensor | 200kg 50kg |
| The machine drive speed | 0-40 km/Hr adjustable |
| The brake force control | closed-loop control |
| Data collection system | The NI acquisition card |
| Main motor | Adopts frequency conversion motor |
| Weight | 400KG |
| Power | AC220V,15A |
Advantages
Integrated Machine includes Road Dynamic Test and Brake Performance Test.
The machine can do tests under both Dry and Wet conditions, which can simulate
actual environment.
It can meet international standards EN 14781, EN 14764, EN14765, especially latest standard ISO 4210.
EN 14781-----Racing bicycles-Safety requirements and test methods
EN 14764-----City and trekking Bicycles-Safety requirements and test methods
EN 14765-----Bicycles for young children-Safety requirements and test methods
ISO 4210------ Cycles. Safety requirements for bicycles
The machine can stop automatically after specimen breakage.
Can be customized according to customers'requirements
