Quick Details
-
Marketing Type:
-
Hot Product
-
Dimension(L*W*H):
-
1100mm*70mm*1000mm
-
Weight:
-
150
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Candle wax melting machine
-
Melting tank:
-
100L 200L 300L 500L(Customizable)
-
Melter Temperature:
-
0-120℃(adjustable)
-
Filling range:
-
10-5000ml adjustable
-
Filling Speed:
-
Max. 2.5L/min
-
Filler Function:
-
Filling, Mixing, Heating
-
Material:
-
Stainless Steel
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Topcn
-
Production Capacity:
-
Max. 2.5L/min
-
Marketing Type:
-
Hot Product
-
Dimension(L*W*H):
-
1100mm*70mm*1000mm
-
Weight:
-
150
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Candle wax melting machine
-
Melting tank:
-
100L 200L 300L 500L(Customizable)
-
Melter Temperature:
-
0-120℃(adjustable)
-
Filling range:
-
10-5000ml adjustable
-
Filling Speed:
-
Max. 2.5L/min
-
Filler Function:
-
Filling, Mixing, Heating
-
Material:
-
Stainless Steel
|
Function
|
Specifications
|
|
Voltage
|
AC 220V 50HZ
|
|
power
|
2.5KW
|
|
Size
|
650L*800W*1700H[CM]
|
|
Barrel size
|
Φ450×470(H)mm
|
|
Barrel volume
|
50L(100L,150L,200L etc)
|
|
Barrel capacity
|
≤50 Kg / barrel / time
|
|
temperature range
|
optimum temperature 80-120 ℃
|
|
Stirring speed
|
0-65 R/M
|
|
Material
|
SUS304
|
|
Net weight
|
about 100KG
|
Parameter:
Good to fill oily liquids:
Liquid oils: cooking oils, salad oils, lubricating oils, engine oils, etc.
(melted)Wax and candle: white wax, beeswax, paraffin wax, scented candles, etc.
|
Model
|
1 head
|
2 head
|
|
|
|||
|
Dimension(L*W*H)
|
41*36*20cm
|
45*38*25cm
|
|
|
|||
|
Package size(L*W*H)
|
57*45*33cm
|
58*45*38cm
|
|
|
|||
|
Weight
|
NW 10.5KG
GW 14KG |
16KG
20KG |
|
|
|||
|
Machinery Capacity
|
500-1000BPH
|
1500-2000BPH
|
|
|
|||
|
Filling volume
|
10-600ml
|
|
|
|
|||
|
Filling Material
|
Oil, Candle, Butter lamp, wax, candle wax, tealight
|
|
|
|
|||
|
Filling Accuracy
|
>100g: ±1.5%
≤100g: ± 2g |
|
|
|
|||
|
Core Components
|
Motor, Pump, Other
|
|
|
|
|||
|
Function
|
Wax Filling
|
|
|
|
|||
|
Filling Speed
|
3L,/min(based on oil); 4/7L customized
|
|
|
|
|||
|
Nozzle type
|
L shape
|
|
|
|
|||
|
Nozzle diameter
|
5*7mm
|
|
|
|
|||
|
Key Selling Points
|
High temperature resistance, easy to operate
|
|
|
|
|||
|
Warranty of core components
|
1 Year
|
|
|
|
|||
Note: This machine is only a filling equipment and has no heating function. The filling of candles needs to be melted by a melter tank in advance. If you need a set including melter tank, please contact us to learn more.
L shape nozzle
convenient for hand-held·All copper made, durable
L handle and button
Easy to hand-held, press once to fill once
Anti-scald
Nozzle SUS304,durable
Cast iron and steel
Temp.resistant <170C and durable
Simple structure
Less block and easy to disassemble
FWD/REV function
Different directions for different purposes:
FWD: (normal filling) feeds in from the inlet hose and flows out from the nozzle
REV- opposite direction: (to expel or remove inside remaining wax after filling) feeds in from the nozzle and flows out from the inlet hose
Related Products
FAQ
Q1: Are you a machine manufacturer or trading company?
A1: We are a reliable machine manufacturer that could gives u best service. And our machine can be customized by client's requirement. Welcome to visit our factory!
Q2: How do you guarantee this machine normally operating?
A2: Every machine is tested by our factory and other client before shipping, We will adjust the machine to optimal effect before delivery. And spare is always available and free for you in warranty year.
Q3: How can I install this machine when it arrives?
A3: We will send the engineers overseas to help client installing, commissioning and training.
Q4: Could I choose the language on touch screen?
A4: It's no problem. You can choose Spanish, French, Italian, Arabic, Korean, etc,.
Q5: What should I do to choose the best machine for us?
A5: 1) Tell me the material you want to fill, we'll choose the suitable type of machine for you to consider.
2) After choose the suitable type of machine, then tell me the filling capacity you need for the machine.
3) At last tell me the inner diameter of your container to help us choose the best diameter of the filling head for you.
Q6: Do you have manual or operation video for us to know more about the machine?
A6: Yes, we will send you the manual and operation video after you ask for us.
Q7: If there's some spare parts that broke, how to solve the problem?
A7: Yes, we will send you the manual and operation video after you ask for us.
Q8: If there's some spare parts that broke, how to solve the problem?
A8: First of all, please take the pic or make a video to show the problem parts.
After the problem is confirm from our sides, we'll send you the spare parts for free, but the shipping cost should be paid by your side.
Q9: Do you have manual or operation video for us to know more about the machine?
A9: Yes, we will send you the manual and operation video after you ask for us.
Q10: If there's some spare parts that broke, how to solve the problem?
A10: Yes, we will send you the manual and operation video after you ask for us.
Q11: If there's some spare parts that broke, how to solve the problem?
A11: First of all, please take the pic or make a video to show the problem parts.
After the problem is confirm from our sides, we'll send you the spare parts for free, but the shipping cost should be paid by your side.
