Quick Details
-
Brand Name:
-
Excelsoo
-
Output Method:
-
RS-485, Wiegand 26/34
-
Reading Angle:
-
Rotation Angle 360°, elevation: ± 55°, Declination: ± 55°
-
Scan Angle:
-
72° (Horizontal) , 54° (Vertical) , 84° (Diagonal)
-
Support Barcode:
-
2D: QR Code, Data Matrix, PDF417, Hanxin Code, etc.
-
Card Supported:
-
ISO1443A/ISO1443B
-
Operating Temperature:
-
-20°C to 60°C
-
Relative Humidity:
-
5% - 95% (non-condensing)
-
Ambient Lighting:
-
Direct sunlight at noon, dim light at night
-
Read Speed:
-
<200ms
-
Input Power:
-
DC12V 500mA (support wide voltage 5~30V)
Quick Details
-
Frequency:
-
13.56Mhz
-
Protocol:
-
ISO 14443A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Excelsoo
-
Output Method:
-
RS-485, Wiegand 26/34
-
Reading Angle:
-
Rotation Angle 360°, elevation: ± 55°, Declination: ± 55°
-
Scan Angle:
-
72° (Horizontal) , 54° (Vertical) , 84° (Diagonal)
-
Support Barcode:
-
2D: QR Code, Data Matrix, PDF417, Hanxin Code, etc.
-
Card Supported:
-
ISO1443A/ISO1443B
-
Operating Temperature:
-
-20°C to 60°C
-
Relative Humidity:
-
5% - 95% (non-condensing)
-
Ambient Lighting:
-
Direct sunlight at noon, dim light at night
-
Read Speed:
-
<200ms
-
Input Power:
-
DC12V 500mA (support wide voltage 5~30V)
Product Description
Specification
|
Item
|
Value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
Excelsoo
|
|
Frequency
|
13.56Mhz
|
|
Protocol
|
ISO 14443A
|
|
Output Method
|
RS-485, Wiegand 26/34
|
|
Reading Angle
|
Rotation Angle 360°, elevation: ± 55°, Declination: ± 55°
|
|
Scan Angle
|
72° (Horizontal) , 54° (Vertical) , 84° (Diagonal)
|
|
Support Barcode
|
2D: QR Code, Data Matrix, PDF417, Hanxin Code, etc.
|
|
Card Supported
|
ISO1443A/ISO1443B
|
|
Operating Temperature
|
-20°C to 60°C
|
|
Relative Humidity
|
5% - 95% (non-condensing)
|
|
Ambient Lighting
|
Direct sunlight at noon, dim light at night
|
|
Read Speed
|
<200ms
|
|
Input Power
|
DC12V 500mA (support wide voltage 5~30V)
|
|
Recognition Distance
|
QR code: 5~30CM; IC card 2-6CM; ID card 1-3CM
|
Packing & Delivery
Paper Box
